Silicone rubber insulated wire UL3123 20AWG electric wire 600V 150C
Price:
Negotiable
MOQ:
5000 pcs
Delivery Time:
7-10 working days
Brand:
MYSUN
Product Description
Silicone rubber insulated wire UL3123 20AWG wire 600V 150C
Specification:
Rated voltage: 600V
Rated temperature: 150C
UL standard: UL758
Applications: this wire widely sued for home appliance, headlamp, industrial machine and etc.
Cable dimensions:
| Conductor | Insulation | Max.Cond Resistance | Unit length | |||
| Size (AWG) |
Construction (No./mm) |
Diameter (mm) |
Nominal Thickness (mm) |
Diameter (mm) |
(Ω/KM) | (M)(Ft) |
| 30 | 7/0.1 | 0.3 | 0.78 | 1.86 | 361 | 305/1000 |
| 28 | 7/0.12 | 0.36 | 0.78 | 1.92 | 227 | 305/1000 |
| 26 | 7/0.16 | 0.48 | 0.78 | 2.04 | 143 | 305/1000 |
| 24 | 7/0.20 | 0.6 | 0.78 | 2.17 | 89.3 | 305/1000 |
| 22 | 7/0.254 | 0.76 | 0.78 | 2.32 | 56.4 | 305/1000 |
| 20 | 7/0.31 | 0.93 | 0.78 | 2.49 | 35.2 | 305/1000 |
| 18 | 7/0.39 | 1.17 | 0.78 | 2.73 | 22.2 | 305/1000 |
| 16 | 7/0.49 | 1.47 | 0.78 | 3.03 | 14 | 305/1000 |
Cable details:
Price term:
EXW, FOB, CIF
Payment terms:
LC, TT, Western Union and PayPal
Lead time:
Sample order: 1-3 working days
Big order: 5-10 working days
Customized order: 10-15 working days
