22AWG flexible wire UL3136 silicone rubber insulated wire solid conductor
Price:
Negotiable
MOQ:
5000 pcs
Delivery Time:
7-10 working days
Brand:
MYSUN
Product Description
22AWG flexible wire UL3136 silicone rubber insulated wire solid conductor
Specification:
Rated voltage: 300V
Rated temperature: 150C
UL standard: UL758
Applications: this wire widely sued for home appliance, headlamp, industrial machine and etc.
Cable dimensions:
| Conductor | Insulation | Max.Cond Resistance | Unit length | |||
| Size (AWG) |
Construction (No./mm) |
Diameter (mm) |
Nominal Thickness (mm) |
Diameter (mm) |
(Ω/KM) | (M)(Ft) |
| 26 | 1/0.4 | 0.4 | 1.15 | 2.7 | 143 | 305/1000 |
| 24 | 1/0.5 | 0.5 | 1.15 | 2.8 | 89.3 | 305/1000 |
| 22 | 1/0.65 | 0.65 | 1.15 | 2.95 | 56.4 | 305/1000 |
| 20 | 1/0.81 | 0.81 | 1.15 | 3.11 | 35.2 | 305/1000 |
Cable details:
Price term:
EXW, FOB, CIF
Payment terms:
LC, TT, Western Union and PayPal
Lead time:
Sample order: 1-3 working days
Big order: 5-10 working days
Customized order: 10-15 working days
