300V Silicone Rubber Insulation Cable UL3122 24awg Fiberglass Stranded Wire
24awg UL3122 Silicone Rubber Insulation wire Fiberglass Stranded for electrical appliance
- Flexibility: silicone rubber insulation with fiberglass braided sleeving
- Maximum conductor resistance: 24.4 ohm/km
- Resistant to oil, hot and cold, flexing
- Rated temperature: -50°C to +200°C
- Rated voltage: 300V
- Insulation potential strength: 2000 VAC/min
- Passes the FT2 flame test
- Available in 16AWG, 18 AWG, 20 AWG, and 22 AWG
| Conductor | Insulation | Max Cond resistance (ohms/m) |
Unit length (m)(F) |
|||||||||||
| 3KV | 6KV | 10KV | 20KV | 30KV | ||||||||||
| Size | Construction | Diameter | Nominal Thickness | Diameter | Nominal Thickness | Diameter | Nominal Thickness | Diameter | Nominal Thickness | Diameter | Nominal Thickness | Diameter | ||
| (AWG) | (NO./mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | ||
| 28 | 7x0.12 | 0.37 | 0.50 | 1.37 | 0.70 | 1.77 | 1.00 | 2.37 | 1.30 | 2.97 | 1.70 | 3.77 | 239 | 610/2000 |
| 26 | 7x0.15 | 0.49 | 0.50 | 1.49 | 0.70 | 1.89 | 1.00 | 2.49 | 1.30 | 3.09 | 1.70 | 3.89 | 150 | 610/2000 |
| 24 | 14x0.14 | 0.60 | 0.50 | 1.60 | 0.70 | 2.00 | 1.00 | 2.60 | 1.30 | 3.20 | 1.70 | 4.00 | 94.2 | 610/2000 |
| 22 | 22x0.14 | 0.76 | 0.50 | 1.76 | 0.70 | 2.14 | 1.00 | 2.76 | 1.30 | 3.36 | 1.70 | 4.16 | 59.4 | 305/1000 |
| 20 | 32x0.14 | 0.91 | 0.50 | 1.91 | 0.70 | 2.31 | 1.00 | 2.91 | 1.30 | 3.50 | 1.70 | 4.31 | 36.7 | 305/1000 |
| 18 | 52x0.14 | 1.17 | 0.50 | 2.17 | 0.70 | 2.57 | 1.00 | 3.17 | 1.30 | 3.77 | 1.70 | 4.57 | 23.2 | 305/1000 |
| 16 | 52x0.18 | 1.50 | 0.50 | 2.50 | 0.70 | 2.90 | 1.00 | 3.50 | 1.30 | 4.10 | 1.70 | 4.90 | 14.6 | 305/1000 |
OUR PRODUCTION
ABOUT US
.Our company specializing in insulation wires and cables for 22 years,we’d like to introduce this item for you,and its further have silicone,(FEP,PFA)XLPE ,PVC,XLPVC s,High temperature insulation tubing wires and cable.Our products had adopted ISO9000,ISO14001,IATF16949 Quality System Authorities with UL.CUL ,CCC,VDE,CSA certificate.
Service:
Shipment:
1. by express
2. by sea
Payment terms:
LC, TT, Western Union, Money Gram and PayPal
Delivery:
Sample order: 1-3 working days
Big order: 5-10 working days
Customized order: 10-15 working days
