LM250WQ4-SSA1 LG Display 2560(RGB)×1440, 400 cd/m² INDUSTRIAL LCD DISPLAY

 whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 552.96(W)×311.04(H) mm, outline size of 565(W)×324.25(H)×14(D) mm, with surface treament of Antiglare (Haze 25%), Hard coating (3H), net weight of 1.99/2.09Kgs (Typ./Max.). As a IPS, Normally Black, Transmissive LCM product, LM250WQ4-SSA1 can provides 400 cd/m² display brightness 1000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 14 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 94% (DCI-P3). This product adopted 9S8P WLED as it's backlight systerm which was placed as Edge light type (Bottom side) and have a working life time of 30K hours, external backlight driver is additionally needed. LM250WQ4-SSA1 utilizes eDP (4 Lanes) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 10.0V (Typ.)
