LB043WV2-SD01 LG Display 4.3" 480(RGB)×800, WVGA 217PPI 600 cd/m² INDUSTRIAL LCD DISPLAY

 whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 56.16(W)×93.6(H) mm, outline size of 60.06(W)×102.97(H)×2.1(D) mm, net weight of 32.5±3.3g. As a IPS, Normally Black, Transmissive LCM product, LB043WV2-SD01 can provides 600 cd/m² display brightness 1000:1 transimissive contrast ratio, 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 40 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 70% (NTSC). This product adopted 5S2P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 15K hours, external backlight driver is additionally needed. LB043WV2-SD01 utilizes Parallel RGB (1 ch, 8-bit) + SPI as it's signal inputting systerm, which connected by 50 pins Connector with power supply voltage of 1.8/2.8/2.8V (Typ.)(IOVCC/VCC/VCI). It's typical vertical frame rate (Fv) is 60Hz. For more latest product detail of LB043WV2-SD01 We strongly recommend that you should refer to datasheet listed on Panelook.com or contact with LG Display or it's distributor.
