AA084XE11 Mitsubishi 8.4INCH 1024×768 RGB 1000CD/M2 WLED LVD INDUSTRIAL LCD DISPLAY
Mitsubishi AA084XE11 Application Details
| Basic Information : | Brand | Model | AA084XE11 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For |
|
|
| Screen Size | 8.4" | Alias | - | |
| Environment : | Storage Temp. | -30 ~~ 80 °C | Operating Temp. | -30 ~~ 80 °C |
| RoHS | Vibration | 1.0G (9.8 m/s²) |
Mitsubishi AA084XE11 Mechanical Details
| Pixel Features : | Resolution | 1024(RGB)×768, XGA | Dot Pitch(mm) | 0.0555×0.1665 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.1665×0.1665 (H×V) [152PPI] | |
| Mechanical Size : | Active Area(mm) | 170.496(H) × 127.872(V) | Bezel Area(mm) | 174.9(H) × 132.2(V) |
| Outline Dim.(mm) | 199.5(H) × 149(V) | Depth(mm) | 9.7 | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type | |
| Mounting : | Face mounting holes (4-Φ3.4) on left, right bezel | |||
| Other Spec : | Weight | 340g (Typ.) | Treatment | Antiglare, Hard coating (3H) |
Mitsubishi AA084XE11 Optical Details
| Basic Information : | Luminance(cd/m²) | 1000 (Typ.) | Contrast Ratio | 800:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive | |
| Best View on | 6 o'clock | Response(ms) | 4/12 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.313; Y:0.329 | Display Colors | 262K/16.7M (6-bit / 8-bit) |
| Color Temperature | 6485K | White Uniformity | 1.30 (Max.)(5 points) | |
| 1931 Color Gamut : | NTSC Ratio | 40% | sRGB | 56% coverage |
| Adobe RGB | 42% coverage | DCI-P3 | 42% coverage | |
| Rec.2020 | 30% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity |
Mitsubishi AA084XE11 Electronics Details
| Frame Rate : | 60Hz |
|---|---|
| Reverse Scan : | Yes (180°) |
| Power Consumption : | 6.7W (Typ.) |
Mitsubishi AA084XE11 Interface Details
| Signal Electrical : | Voltage Supply | 3.3V (Typ.) | Current Supply | 365/660mA (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Consumption | 1.21W (Typ.) | |||||
| Signal Type : | LVDS (1 ch, 6/8-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| I-PEX | 20186-202E-11F | 1 pcs | 20 pins | 1.25 mm | LVDS-20P1C8B-010H | |
Mitsubishi AA084XE11 Backlight Details
| Backlight Features: | Shape | 2 strings | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | No | Quantity | 2 strings | Life Time | 100K(Typ.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 21.9/25.3V (Typ./Max.) | Current Supply | 125/135mA (Typ./Max.) | ||
| Consumption | 5.48W (Typ.) | |||||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JST | SM06B-SHLS-TF(LF)(SN) | 1 pcs | 6 pins | 1.0 mm | BLE-6PINS-NNCAAC | |
| Backlight Driver : | No | |||||
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 170.496(W)×127.872(H) mm, outline size of 199.5(W)×149(H) mm, viewing area size of 174.9(W)×132.2(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 340g (Typ.). As a TN, Normally White, Transmissive LCM product, AA084XE11 can provides 1000 cd/m² display brightness 800:1 transimissive contrast ratio, 80/80/80/60 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 4/12 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit / 8-bit gray scale signal for each dot, thus presenting a palette of 262K/16.7M colors, also with performance of color gamut 40% (NTSC). This product adopted 2 strings WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 100K hours, external backlight driver is additionally needed. AA084XE11 utilizes LVDS (1 ch, 6/8-bit) as it's signal inputting systerm, which connected by 20 pins Connector with power supply voltage of 3.3V (Typ.).
