SP14Q002-A1 HITACHI 5.7 inch 320×240 140 cd/m² Storage Temperature: -20 ~ 60 °C INDUSTRIAL LCD DISPLAY
MOQ:
1PCS
Delivery Time:
1-3 DAYS
Brand:
HITACHI
Product Description
HITACHI SP14Q002-A1 Application Features
| Basic Information : | Manufacturer | Panel Model | Panel Type | Alias |
|---|---|---|---|---|
| SP14Q002-A1 | FSTN-LCD , LCM | - | ||
| Environment : | RoHS State | Operating Temp. | Storage Temp. | Vibration Level |
| 0 ~ 50 °C | -20 ~ 60 °C | - | ||
| Used For : | ||||
| Specific Features : | ||||
HITACHI SP14Q002-A1 Optical Features
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
|---|---|---|---|
| 140 (Typ.) | 40 (Typ.)(CR≥2, Φ2-Φ1) | 120/150 (Typ.)(Tr/Td) | |
| Best View on | Display Mode | Contrast Ratio | |
| 6 o'clock | STN, Black/White (Negative), Transmissive | 25 : 1 (Typ.) (Transmissive) | |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| - | Monochrome |
HITACHI SP14Q002-A1 Mechanical Features
| Panel Size : | 5.7" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
| 320×240 [QVGA] | Rectangle | 0.360×0.360 [70PPI] | 0.360×0.360 | |
| Mechanical Size : | Active Area (mm) | Bezel Area (mm) | Outline Dimension (mm) | Outline Depth (mm) |
| 115.185(H) × 86.385(V) | 122.0(H) × 92.0(V) | 167(H) × 109(V) | 8.5/10.0 (Typ.Max.) mm | |
| Outline Features : | Form Factor | Orientation | Aspect Ratio | Shape Style |
| Flat Rectangle | Landscape type | 4:3 (H:V) | ||
| Mounting : | Face mounting holes (4-Φ3.5) on left, right bezel | |||
| Other Detail : | Weight | Panel Cover | Treatment | |
| - | - | Antiglare | ||
HITACHI SP14Q002-A1 Electronics Features
| Reverse Scan : | No |
|---|---|
| Vertical Frequency : | 75Hz |
| Driving Method : | Duty: 1/240 |
HITACHI SP14Q002-A1 Backlight Features
| Lamp Features: | Type | Position | Quantity | Shape | Life(Hours) | Lamp Exchange |
|---|---|---|---|---|---|---|
| CCFL | Edge light type | 1 pcs | Straight | - | - | |
| CCFL Electrical : | Voltage Supply | Current Supply | Power | |||
| 300V (Typ.) | 5.0±1.0mA | |||||
| Operating Frequency | Kick-off Voltage | |||||
| 70/85KHz (Typ./Max.) | 1000V (Min.)(Ta=+25℃) | |||||
| Interface Features : | Position | Backlight Driver | Type | |||
| - | No | Connector | ||||
| Interface Detail : | Brand | Model | Pin Pitch | Pin Amount | Quantity | Configuration |
| JAE | IL-G-4S-S3C2 | 2.5 mm | 4 pins | 1 pcs | BLL-4PINS-HNNL | |
HITACHI SP14Q002-A1 Interface Features
| Panel Driving Electrical : | Voltage Supply | Current Supply | Power | |||
|---|---|---|---|---|---|---|
| 3.3/5.0V (Typ.)(VDD) | - | - | ||||
| Interface Features : | Position | Signal | Type | |||
| - | Parallel Data (4-bit) | FPC | ||||
| FPC Detail : | Brand | Model | Pin Pitch | Pin Amount | Quantity | Configuration |
| 1.25 mm | 14 pins | 1 pcs | PD-14P1C4B-010A | |||
