TM030LDH01 TIANMA 3.0" 240(RGB)×400 250 cd/m² INDUSTRIAL LCD DISPLAY
Price:
Negotiable
MOQ:
1PCS
Delivery Time:
1-2 DAYS
Brand:
TIANMA
Product Description
TIANMA TM030LDH01 Application Features
| Basic Information : | Brand | Model | Type | Model Alias |
|---|---|---|---|---|
| TM030LDH01 | a-Si TFT-LCD , LCM | - | ||
| Reliability : | RoHS | Operating Temperature | Storage Temperature | Vibration Resistance |
TIANMA TM030LDH01 Mechanical Features
| Panel Size : | 3.0 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 240(RGB)×400, WQVGA | RGB Vertical Stripe | - | - [156PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 38.88×64.8 mm | - | 43.48×74.9 mm | 1.90 mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | 3:5 (W : H) | Portrait type | ||
TIANMA TM030LDH01 Optical Features
Basic Information : Brightness Operating Mode Contrast Ratio
250 cd/m² (Typ.) TN, Normally White, Transmissive 500:1 (Typ.) (Transmissive)
Viewing Angle(L/R/U/D) Viewing Direction Response Speed
70/70/70/60 (Typ.)(CR≥10)
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 38.88(W)×64.8(H) mm, outline size of 43.48(W)×74.9(H) mm. As a TN, Normally White, Transmissive LCM product, TM030LDH01 can provides 250 cd/m² display brightness 500:1 transimissive contrast ratio, 70/70/70/60 (Typ.)(CR≥10) (L/R/U/D) viewing angle .. This product adopted WLED as it's backlight systerm which was placed as Edge light type. TM030LDH01 utilizes TTL as it's signal inputting systerm. For more latest product detail of TM030LDH01 we strongly recommend that you should refer to datasheet listed on Panelook.com or contact with TIANMA.
