LQ7BW566 Sharp 7" LCM 480×234RGB 300 cd/m² INDUSTRIAL LCD DISPLAY
Price:
Negotiable
MOQ:
1PCS
Delivery Time:
1-2DAYS
Brand:
Sharp
Product Description
Sharp LQ7BW566 Application Details
| Basic Detail : | Manufacturer | Model Name | LQ7BW566 | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 7.0 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | -30 ~ 85 °C | ST Temperature | -30 ~ 85 °C |
| Vibration Level | - | RoHS |
Sharp LQ7BW566 Optical Details
| Basic Information : | Luminance | 300 cd/m² (Typ.) | Contrast Ratio | 60 : 1 (Min.) (Transmissive) |
|---|---|---|---|---|
| Good View at | 6 o'clock | Response Speed | 30/50 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 65/65/40/65 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Support Color | Full color |
| Color Temperature | 6485K | White Uniformity |
Sharp LQ7BW566 Mechanical Details
| Pixel Features : | Number of Pixel | 480(RGB)×234 | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.108×0.375 mm | Pixel Pitch(W×H) | 0.324×0.375 mm [75PPI] | |
| Physical Size : | Active Viewing | 155.52(W)×87.75(H) mm | Overall Dim. | 173(W)×106(H) mm |
| Bezel Opening | - | Overall Depth | 14.7±0.5 mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 16:9 | Shape Style | ||
| Fixation : | Rear mounting holes (4-Φ2.6) | |||
| Other Detail : | Mass | 320±20g | Surface | Antiglare, Antireflection |
Sharp LQ7BW566 Electronics Details
| Refresh Rate : | 60Hz |
|---|---|
| Reverse Scan : | Yes (U/D, L/R) |
| Power Consumption : | 5.45W (Typ.) |
| Time Controller (T-CON) : | Embedded T-CON |
Sharp LQ7BW566 Interface Details
| Signal Electrical : | Input Current | 75/0.9/2.8mA (Typ.)(ISH/IGH/IGL) | Input Voltage | 5.3/13/-16V (Typ.)(VSH/VGH/VGL) | ||
|---|---|---|---|---|---|---|
| Consumption | 454/558mW (Typ./Max.) | Signal Interface | Analog RGB + Composite Video (NTSC/PAL) | |||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| FCI | SFR24R-1STE1 | 1 pcs | 0.8 mm | 24 pins | ||
Sharp LQ7BW566 Lightting Details
| Lamp Features: | Lamp Shape | - | Lamp Type | CCFL | Position | Direct light type |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | 2 pcs | Life | 10K(Min.) (Hours) | |
| Lamp Electrical : | Input Current | 3.0/6.5/7.0mA (Min./Typ./Max.) | Input Voltage | 380±40V | ||
| Frequency | 30/70KHz (Min./Max.) | Turn-on Voltage | 950/1100V (Max.)(Ta=+25/-30℃) | |||
| Consumption | 5.0/5.9W (Typ.Max.) | |||||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Interface Detail : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| JST | BHR-02(8.0)VS-1N | 2 pcs | 8.0 mm | 2 pins | BLL-2PINS-HL | |
| Backlight Driver : | No | |||||
