LQ231U1LW21 Sharp 23.1" LCM 1600×1200RGB 250cd/m² INDUSTRIAL LCD DISPLAY
Price:
Negotiable
MOQ:
1PCS
Delivery Time:
1-2DAYS
Brand:
Sharp
Product Description
LQ231 Series LQ231U1LW32 LQ231U1LW31 LQ231U1LW21
Sharp LQ231U1LW21 Application Details
| Basic Information : | Brand | SHARP | Model | LQ231U1LW21 |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 23.1" | Alias | - | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 45 °C |
| Typical Features : | ||||
| Remarks : | Expanded backlight brightness adjustment area | |||
Sharp LQ231U1LW21 Mechanical Details
| Pixel Features : | Resolution | 1600(RGB)×1200, UXGA | Dot Pitch(mm) | 0.098×0.294 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.294×0.294 (H×V) [86PPI] | |
| Mechanical Size : | Active Area(mm) | 470.4(H) × 352.8(V) | Bezel Area(mm) | - |
| Outline Dim.(mm) | 530(H) × 432.8(V) | Depth(mm) | 32.5 (Typ.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | 5.50Kgs (Max.) | Treatment | - |
Sharp LQ231U1LW21 Optical Details
| Basic Information : | Luminance(cd/m²) | 250 (Typ.) | Contrast Ratio | - |
|---|---|---|---|---|
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) | Display Mode | Transmissive | |
| Best View on | - | Response(ms) | - | |
| Color Performance : | White Coordinate | - | Display Colors | 16.7M (8-bit) |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
