AT043TN24 V.4 Innolux 4.3" 480(RGB)×272 400 cd/m² INDUSTRIAL LCD DISPLAY
Price:
Negotiable
MOQ:
1PCS
Delivery Time:
1-2 DAYS
Brand:
INNOLUX
Product Description
Innolux AT043TN24 V.4 Application Details
| Basic Detail : | Manufacturer | Model Name | AT043TN24 V.4 | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | AT043TN24 V4 | |
| Panel Size | 4.3 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | -20 ~ 70 °C | ST Temperature | -30 ~ 85 °C |
| Vibration Level | - | RoHS | ||
| Features : |
|
|||
| Remarks : | 3 in 1 FPC | |||
Innolux AT043TN24 V.4 Optical Details
| Basic Information : | Luminance | 400 cd/m² (Typ.) | Contrast Ratio | 500 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | 6 o'clock | Response Speed | 10/15 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.310; Wy:0.330 | Support Color | 262K (6-bit) |
| Color Temperature | 6638K | White Uniformity | 1.33/1.43 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 51% | sRGB | 69% coverage |
| Adobe RGB | 53% coverage | DCI-P3 | 52% coverage | |
| Rec.2020 | 38% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
Innolux AT043TN24 V.4 Mechanical Details
| Pixel Features : | Number of Pixel | 480(RGB)×272 [WQVGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.066×0.198 mm | Pixel Pitch(W×H) | 0.198×0.198 mm [128PPI] | |
| Physical Size : | Active Viewing | 95.04(W)×53.856(H) mm | Overall Dim. | 105.5(W)×67.2(H) mm |
| Bezel Opening | 98.7(W)×57.5(H) mm | Overall Depth | 4.2±0.2 mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 16:9 | Shape Style | ||
| Touchscreen : | TP Controller | - | TP Interface | - |
| Touch Points | - | TP Technology | 4-wire Resistive Touch | |
| Other Detail : | Mass | 63.0g (Typ.) | Surface | Glare (Haze 0%) |
Innolux AT043TN24 V.4 Electronics Details
| Refresh Rate : | 60Hz |
|---|---|
| Reverse Scan : | No |
| Power Consumption : | 616mW (Typ.) |
| Time Controller (T-CON) : | Embedded T-CON |
Innolux AT043TN24 V.4 Interface Details
| Signal Electrical : | Input Current | 14/0.04mA (Typ.)(IAVDD/IDVDD) | Input Voltage | 3.3/1.8V (Typ.)(AVDD/DVDD) | ||
|---|---|---|---|---|---|---|
| Consumption | 46mW (Typ.) | Signal Interface | Parallel RGB (1 ch, 6-bit) | |||
| Logic Voltage for Signals : | 0≤VIL≤0.2DVDD; 0.8DVDD≤VIH≤DVDD | |||||
| Interface Features : | Position | - | Physical Type | FPC | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| 1 pcs | 0.3 mm | 67 pins | ||||
Innolux AT043TN24 V.4 Lightting Details
| Lamp Features: | Lamp Shape | 1 string | Lamp Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | 9S1P | Life | 20K(Min.) (Hours) | |
| Lamp Electrical : | Input Current | 20±2mA | Input Voltage | 28.8/31.5 (Typ./Max.) | ||
| Consumption | 0.576W (Typ.) | |||||
| Interface Features : | Position | - | Physical Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
Innolux AT043TN24 V.4 Packing Details
| Package Box : | Amount | Size (L×W×H) | Weight |
|---|---|---|---|
| 112 pcs / box | 530×355×255 mm | 13.216±0.05 Kgs |
