AT043TN25 V.1 Innolux 4.3" 480(RGB)×272 500 cd/m² INDUSTRIAL LCD DISPLAY

Price Negotiable
Price: Negotiable
MOQ: 1PCS
Delivery Time: 1-2 DAYS
Brand: INNOLUX
Product Description



Innolux AT043TN25 V.1 Optical Details

Basic Information :
Brightness
500 cd/m² (Typ.)
Contrast Ratio
500:1 (Typ.) (Transmissive)
Viewing Angle
70/70/50/70 (Typ.)(CR≥10)
Optical Mode
TN, Normally White, Transmissive
Viewing Direction
6 o'clock
Response Time
10/15 (Typ.)(Tr/Td) ms
Color Performance :
Chromaticity
Wx:0.310; Wy:0.330
Color Numbers
262K (6-bit)
Color Temperature
6638K
Uniformity
1.33/1.43 (Typ./Max.)(9 points)
1931 Color Gamut :
NTSC Ratio
44%
sRGB
61% coverage
Adobe RGB
46% coverage
DCI-P3
46% coverage
Rec.2020
33% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



Innolux AT043TN25 V.1 Mechanical Details

Pixel Features :
Pixel Format
480(RGB)×272, WQVGA
Dot Pitch
0.066×0.198 mm (H×V)
Configuration
RGB Vertical Stripe
Pixel Pitch
0.198×0.198 mm (H×V) [128PPI]
Mechanical Size :
Display Area
95.04×53.856 mm (H×V)
Bezel Area
98.7×57.5 mm (H×V)
Outline Dim.
105.5×67.2 mm (H×V)
Outline Depth
3.05±0.2 mm
Outline Features :
Form Factor
Flat Rectangle
Orientation
Landscape type
Aspect Ratio
16:9 (H:V)
Shape Style

Other Features :
Weight
TBD
Surface
Antiglare



Innolux AT043TN25 V.1 Backlight Details

Back-light Features :
Lamp Type
WLED
Amount
9S1P
Life Time
20K(Min.) (Hours)
Replacement
-
Lamp Shape
1 string
Position
Edge light type
Lamp Electrical :
Voltage Input
28.8/31.5V (Typ./Max.)
Current Input
20±2mA
Consumption
0.576W (Typ.)
Interface Features :
Type
Included in signal interface
Position
-
Lamp Driver
No



Innolux AT043TN25 V.1 Interface Detail

Signal Systerm :
Parallel RGB (1 ch, 6-bit) + SPI
Logic Voltage
0≤VIL≤0.2VDD; 0.8VDD≤VIH≤VDD
Signal Electrical :
Voltage Input
1.8/3.3V (Typ.)(DVDD/AVDD)
Current Input
-
Consumption
0.046W (Typ.)
Interface Features :
Type
FPC
Position
-
FPC Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration


0.3 mm
67 pins
1 pcs
