LQ121X1LH73 Sharp 12.1" LCM 1024×768RGB  200cd/m² INDUSTRIAL LCD DISPLAY

Price Negotiable
Price: Negotiable
MOQ: 1PCS
Delivery Time: 1-2 DAYS
Brand: SHARP
Product Description

LQ121 Series LQ121X3LH01 LQ121X3LG02 LQ121X1LH83 LQ121X1LH73





Sharp LQ121X1LH73 Optical Details

Basic Detail :
Luminance
200 cd/m² (Typ.)
Contrast Ratio
300:1 (Typ.) (Transmissive)
Good View at
6 o'clock
Response Speed
30 (Typ.)(Tr+Td) ms
Viewing Angle
45/45/10/30 (Min.)(CR≥10)
Operating Mode
TN, Normally White, Transmissive
Color Performance :
Chromaticity
Wx:0.313; Wy:0.329
Support Color
262K (6-bit)
Color Temperature
6485K
White Variation
1.10/1.30 (Typ./Max.)(5 points)





Sharp LQ121X1LH73 Mechanical Details

Pixel Features :
Number of Pixel
1024(RGB)×768, XGA
Arrangement
RGB Vertical Stripe
Dot Pitch(W×H)
0.080×0.240 mm
Pixel Pitch(W×H)
0.240×0.240 mm [105PPI]
Physical Size :
Active Viewing
245.76(W)×184.32(H) mm
Overall Dim.
260(W)×197.5(H) mm
Bezel Opening
-
Overall Depth
5.55 (Max.) mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
4:3
Shape Style

Other Detail :
Mass
245g (Typ.)
Surface
Antiglare, Hard coating (2H), Antireflection





Sharp LQ121X1LH73 Interface Detail

Signal Electrical :
Input Current
235mA (Typ.)
Input Voltage
3.3V (Typ.)
Consumption
-
Signal Interface
LVDS (1 ch, 6-bit)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
HRS
DF19L-20P-1H
1.0 mm
20 pins
1 pcs
LVDS-20P1C6B-070A





Sharp LQ121X1LH73 Lightting Details

Lamp Features :
Lamp Type
CCFL
Amount
1 pcs
Position
Edge light type
Exchange
-
Lamp Shape
Straight
Lamp Life
10K(Min.) (Hours)
Lamp Electrical :
Input Voltage
635V (Typ.)
Input Current
3.0/4.2/5.0mA (Min./Typ./Max.)
Frequency
45/70/80KHz (Min./Typ./Max.)
Turn-on Voltage
1030/1200V (Max.)(Ta=+25/0℃)
Consumption
2.67W (Typ.)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
JST
BHTR-02VS
5.1 mm
2 pins
1 pcs
BLL-2PINS-HL
Backlight Driver :
No
