JJ103IA-A7B Innolux 10.3" 1920(RGB)×720 800 cd/m² INDUSTRIAL LCD DISPLAY

Price Negotiable
Price: Negotiable
MOQ: 1PCS
Delivery Time: 1-2 DAYS
Brand: INNOLUX
Product Description

Innolux JJ103IA-A7B Application Details

Basic Info :
Panel Brand

JJ103IA-A7BPanel Model
Diagonal Size
10.3"
Application

a-Si TFT-LCD , LCMPanel Type
Model Alias
-
Reliability :
Operating Temp.
-30 ~ 85 °C
Storage Temp.
-40 ~ 90 °C
RoHS State

2.0G (19.6 m/s²)Vibration Rating



Innolux JJ103IA-A7B Mechanical Details

Pixel Features :
Pixel Format
1920(RGB)×720
Dot Pitch
0.0423×0.1269 mm (H×V)
Configuration
RGB Vertical Stripe
Pixel Pitch
0.1269×0.1269 mm (H×V) [200PPI]
Mechanical Size :
Display Area
243.648×91.368 mm (H×V)
Bezel Area
246.65×94.37 mm (H×V)
Outline Dim.
260.15×110.5 mm (H×V)
Outline Depth
6.52 (Typ.) mm
Outline Features :
Form Factor
Flat Rectangle
Orientation
Landscape type
Aspect Ratio
8:3 (H:V)
Shape Style

Holes & Brackets :
Rear mounting holes Pole (5 pcs)
Other Features :
Weight
380g (Max.)
Surface



Innolux JJ103IA-A7B Optical Details

Basic Information :
Brightness
800 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (Transmissive)
Viewing Angle
80/80/80/80 (Min.)(CR≥10)
Optical Mode
IPS, Normally Black, Transmissive
Viewing Direction
Symmetry
Response Time
30 (Max.)(Tr+Td) ms
Color Performance :
Chromaticity
Wx:0.310; Wy:0.330
Color Numbers
16.7M (8-bit)
Color Temperature
6638K
Uniformity
1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
71%
sRGB
97% coverage
Adobe RGB
73% coverage
DCI-P3
74% coverage
Rec.2020
53% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance :
Outdoor Visibility
Sunlight Readable
Transmittance
-



Innolux JJ103IA-A7B Electronics Details

Frame Frequency :
60Hz
Reverse Scan :
Yes (U/D, L/R)



Innolux JJ103IA-A7B Backlight Details

Back-light Features :
Lamp Type
WLED
Amount
10S4P
Life Time
10K(Min.) (Hours)
Replacement
-
Lamp Shape
4 strings
Position
Edge light type
Lamp Electrical :
Voltage Input
21±2.0V
Current Input
240mA (Typ.)
Consumption
7.44W (Typ.)
Interface Features :
Type
FPC
Position
-
Lamp Driver
No
Interface Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration



10 pins
1 pcs



Innolux JJ103IA-A7B Interface Detail

Signal Systerm :
LVDS (2 ch, 8-bit)
Logic Voltage
-
Signal Electrical :
Voltage Input
3.3V (Typ.)
Current Input
TBD
Consumption
TBD
Interface Features :
Type
FPC
Position
-
FPC Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration



50 pins
1 pcs



FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
