T-51963GD035J-MLW-AJN Kyocera 3.5INCH LCM 240×320RGB 300NITS WLED TTL INDUSTRIAL LCD DISPLAY
Price:
Negotiable
MOQ:
1PCS
Delivery Time:
1-2day
Brand:
Kyocera
Product Description
OPTREX T-51963GD035J-MLW-AJN Application Details
| Basic Info : | Panel Brand | Panel Model | T-51963GD035J-MLW-AJN | |
|---|---|---|---|---|
| Diagonal Size | 3.5" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | -20 ~ 70 °C | Storage Temp. | -30 ~ 70 °C |
| RoHS State | Vibration Rating | - |
OPTREX T-51963GD035J-MLW-AJN Mechanical Details
| Pixel Features : | Pixel Format | 240(RGB)×320 [QVGA] | Dot Pitch | 0.0745×0.2235 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.2235×0.2235 mm (H×V) [113PPI] | |
| Mechanical Size : | Display Area | 53.64×71.52 mm (H×V) | Bezel Area | - |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Portrait type |
| Aspect Ratio | 3:4 (H:V) | Shape Style |
OPTREX T-51963GD035J-MLW-AJN Optical Details
| Basic Information : | Brightness | - | Contrast Ratio | 70:1 (Typ.) (Transmissive) 8:1 (Typ.) (Reflective) |
|---|---|---|---|---|
| Viewing Angle | 40/40/40/40 (Typ.)(CR≥10) | Optical Mode | TN, Normally White, Transflective | |
| Viewing Direction | - | Response Time | 30/50 (Typ.)(Tr/Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.320; Wy:0.350 | Color Numbers | 262K (6-bit) |
| Color Temperature | 6022K | White Uniformity | 1.43 (Max.)(5 points) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmittance | - |
| 3D Type | - | Reflectance | 20% (Typ.) |
OPTREX T-51963GD035J-MLW-AJN Electronics Details
| Frame Frequency : | 60Hz |
|---|---|
| Time Controller (T-CON) : | Embedded T-CON |
OPTREX T-51963GD035J-MLW-AJN Backlight Details
| Back-light Features: | Lamp Shape | - | Lamp Type | WLED | Life Time | - |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | - | Position | Edge light type | |
| Interface Features : | Type | Included in panel signal interface | Position | - | Lamp Driver | No |
OPTREX T-51963GD035J-MLW-AJN Interface Details
| Signal Systerm : | CMOS (1 ch, 6-bit) | Logic Voltage | ||
|---|---|---|---|---|
