M170E5-L09 CMO 17.0" 1280(RGB)×1024 300 cd/m² INDUSTRIAL LCD DISPLAY
Price:
Negotiable
MOQ:
1PCS
Delivery Time:
1-2 DAYS
Brand:
CMO
Product Description
CMO M170E5-L09 Application Details
| Basic Detail : | Manufacturer | Model Name | M170E5-L09 3 Compatible | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 17.0 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | 0 ~ 50 °C | ST Temperature | -20 ~ 60 °C |
| Vibration Level | - | RoHS | ||
| Features : | ||||
| Remarks : | High color saturation | |||
CMO M170E5-L09 Optical Details
| Basic Information : | Luminance | 300 cd/m² (Typ.) | Contrast Ratio | 600 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | - | Response Speed | 2/6 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 88/88/80/80 (Typ.)(CR≥5) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Support Color | 16.2M (6-bit + FRC) |
| Color Temperature | 6485K | White Uniformity | 1.25/1.33 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 73% | sRGB | 93% coverage |
| Adobe RGB | 76% coverage | DCI-P3 | 76% coverage | |
| Rec.2020 | 55% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
CMO M170E5-L09 Mechanical Details
| Pixel Features : | Number of Pixel | 1280(RGB)×1024 [SXGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.088×0.264 mm | Pixel Pitch(W×H) | 0.264×0.264 mm [96PPI] | |
| Physical Size : | Active Viewing | 337.92(W)×270.336(H) mm | Overall Dim. | 358.5(W)×296.5(H) mm |
| Bezel Opening | 341.9(W)×274.4(H) mm | Overall Depth | 17.0±0.5 mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 5:4 | Shape Style | Normal bezel | |
| Fixation : | Side mounting holes (8-M3) on left, right bezel | |||
| Other Detail : | Mass | 2.23/2.25Kgs (Typ./Max.) | Surface | Antiglare (Haze 25%), Hard coating (3H) |
CMO M170E5-L09 Electronics Details
| Refresh Rate : | 60Hz |
|---|---|
| Reverse Scan : | No |
CMO M170E5-L09 Interface Details
| Signal Electrical : | Input Current | 0.81/1.13mA (Typ./Max.) | Input Voltage | 5.0V (Typ.) | ||
|---|---|---|---|---|---|---|
| Consumption | - | Signal Interface | LVDS (2 ch, 8-bit) | |||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| JAE | FI-XB30SRL-HF11 | 1 pcs | 1.0 mm | 30 pins | LVDS-30P2C8B-160D | |
CMO M170E5-L09 Lightting Details
| Lamp Features: | Lamp Shape | Straight | Lamp Type | CCFL | Position | Edge light type (Top and Bottom) |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | 4 pcs | Life | 40K(Min.) (Hours) | |
| Lamp Electrical : | Input Current | 2.0/7.0/7.5mA (Min./Typ./Max.) | Input Voltage | 640±64V | ||
| Frequency | 40/60/80KHz (Min./Typ./Max.) | Turn-on Voltage | 1260/1500V (Max.)(Ta=+25/0℃) | |||
| Consumption | 17.92W (Typ.) | |||||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Interface Detail : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| JST | BHSR-02VS-1 | 4 pcs | 3.5 mm | 2 pins | BLL-2PINS-HL | |
| Backlight Driver : | No | |||||
CMO M170E5-L09 Packing Details
| Package Box : | Amount | Size (L×W×H) | Weight |
|---|---|---|---|
| 5 pcs / box | 537×316×462 mm | 12 Kgs |
