LQ055W1GC01 Sharp 5.5INCH LCM 1024×600RGB 200cd/m² INDUSTRIAL LCD DISPLAY
Price:
Negotiable
MOQ:
1PCS
Delivery Time:
1-2DAYS
Brand:
Sharp
Product Description
Sharp LQ055W1GC01 Optical Features
| Basic Information : | Luminance | Work Mode | Contrast Ratio |
|---|---|---|---|
| 200 cd/m² (Typ.) | TN, Normally White, Transmissive | 300:1 (Typ.) (Transmissive) | |
| Good View at | Viewing Angle | Response Time | |
| 9 o'clock | 60/50/70/70 (Typ.)(CR≥10) | 25 (Typ.)(Tr+Td) (ms) | |
| Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
| 6485K | 262K (6-bit) | X:0.313; Y:0.329 |
Sharp LQ055W1GC01 Mechanical Features
| Screen Size : | 5.5" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 1024(RGB)×600, WSVGA | RGB Vertical Stripe | 0.039×0.117 mm | 0.117×0.117 mm [217PPI] | |
| Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 119.808×70.2 mm | - | 130.2×81.15 mm | 1.95/2.15 (Typ./Max.) mm | |
| Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 17:10 | Landscape type | ||
| Other Spec : | Mass | Panel Cover | Surface Treatment | |
| 32.0/36.0g (Typ./Max.) | - | Clear, Hard coating (2H) | ||
Sharp LQ055W1GC01 Interface Features
| Signal Electrical : | Input Voltage | Input Current | Power Consumption | |||
|---|---|---|---|---|---|---|
| 2.5/7.9V (Typ.)(VCC/VDD) | 9.0/14.0mA (Typ.)(ICC/IDD) | - | ||||
| Interface Features : | Signal Type | Physical Type | Interface Position | |||
| Mini LVDS | FPC | - | ||||
| Interface Detail : | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
| 1 pcs | 40 pins | 0.5 mm | ||||
Sharp LQ055W1GC01 Backlight Features
| Back-light Features: | Type | Position | Life(Hours) | Amount | Shape | Replacement |
|---|---|---|---|---|---|---|
| WLED | Edge light type | - | 8S1P | 1 string | - (NSSW206A (NICHIA)) | |
| WLED Electrical : | Input Voltage | Input Current | Power Consumption | |||
| 21.6/22.7V (Typ.)(100cd/200cd) | 6.0/12.0mA (Typ.)(100cd/200cd) | 130/273mW (Typ.)(100cd/200cd) | ||||
| Interface Features : | WLED Driver State | Physical Type | Interface Position | |||
| No | Included in panel signal interface | - | ||||
