R213T1-L01 CMO 21.3" 2560(RGB)×2048 1000 cd/m² INDUSTRIAL LCD DISPLAY
Price:
Negotiable
MOQ:
1PCS
Delivery Time:
1-2 DAYS
Brand:
INNOLUX
Product Description
CMO R213T1-L01 Application Details
| Basic Information : | Brand | Model | R213T1-L01 1 Compatible | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 21.3" | Alias | IAQS80F | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 50 °C |
CMO R213T1-L01 Mechanical Details
| Pixel Features : | Resolution | 2560(LCR)×2048, QSXGA | Dot Pitch(mm) | 0.055×0.165 (H×V) |
|---|---|---|---|---|
| Pixel Format | LCR Vertical Stripe | Pixel Pitch(mm) | 0.165×0.165 (H×V) [153PPI] | |
| Mechanical Size : | Active Area(mm) | 422.4(H) × 337.92(V) | Bezel Area(mm) | 426.4(H) × 344.5(V) |
| Outline Dim.(mm) | 459.8(H) × 375.3(V) | Depth(mm) | 49.0 (Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 5:4 (H:V) | Orientation | Landscape type | |
| Mounting : | Side mounting holes (6-M3) on left, right bezel | |||
| Other Spec : | Weight | 2.97Kgs (Typ.) | Treatment | - |
CMO R213T1-L01 Optical Details
| Basic Information : | Luminance(cd/m²) | 1000 (Typ.) | Contrast Ratio | 700:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Display Mode | DD-IPS, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 25/25 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.294; Y:0.309 | Display Colors | Grayscale (8-bit) |
| Color Temperature | 7984K | White Uniformity | - | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity |
CMO R213T1-L01 Interface Details
| Signal Electrical : | Voltage Supply | 12.0V (Typ.) | Current Supply | 0.7/1.7A (Min./Max.) | ||
|---|---|---|---|---|---|---|
| Consumption | 8.1/18.3W (Typ.) | |||||
| Signal Type : | LVDS (4 ch, 8-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JAE | FI-X30S-HF-NPB | 2 pcs | 30 pins | 1.0 mm | ||
| JAE | IL-Z-8PL-SMTY | 1 pcs | 8 pins | 1.25 mm | ||
| JAE | IL-Z-5PL-SMTY | 1 pcs | 5 pins | 1.25 mm | ||
CMO R213T1-L01 Backlight Details
| Backlight Features: | Shape | Straight | Type | CCFL | Position | Direct light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | 12 pcs | Life Time | 50K(Typ.) (Hours) | |
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JST | B12B-PH-SM4-TB(LF)(SN) | 1 pcs | 12 pins | 2.0 mm | ||
| Backlight Driver : | With Inverter | |||||
| Driver Electrical : | Voltage Supply | 12.0V (Typ.) | Current Supply | 3.0/3.7/4.2A (Min./Typ./Max.) | ||
| Consumption | 44/50W (Typ./Max.) | |||||
CMO R213T1-L01 Electronics Details
| Frame Rate : | 60Hz |
|---|---|
| Reverse Scan : | No |
| Power Consumption : | 52.1W (Typ.) |
