ZJ050NA-05B CHIMEI Innolux 5.0" 480(RGB)×272 500 cd/m² INDUSTRIAL LCD DISPLAY
Price:
Negotiable
MOQ:
1PCS
Delivery Time:
1-2 DAYS
Brand:
INNOLUX
Product Description
Chimei Innolux ZJ050NA-05B Application Details
| Basic Information : | Brand | Model | ZJ050NA-05B | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 5.0" | Alias | - | |
| Environment : | Storage Temp. | -30 ~~ 85 °C | Operating Temp. | -20 ~~ 70 °C |
Chimei Innolux ZJ050NA-05B Mechanical Details
| Pixel Features : | Resolution | 480(RGB)×272, WQVGA | Dot Pitch(mm) | 0.077×0.231 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.231×0.231 (H×V) [109PPI] | |
| Mechanical Size : | Active Area(mm) | 110.88(H) × 62.832(V) | Bezel Area(mm) | 113.9(H) × 65.85(V) |
| Outline Dim.(mm) | 120.7(H) × 75.8(V) | Depth(mm) | 3.1±0.2 | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | 63.0g (Typ.) | Treatment | Antiglare |
Chimei Innolux ZJ050NA-05B Optical Details
| Basic Information : | Luminance(cd/m²) | 500 (Typ.) | Contrast Ratio | 500:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive | |
| Best View on | 6 o'clock | Response(ms) | 10/15 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.310; Y:0.330 | Display Colors | 262K (6-bit) |
| Color Temperature | 6638K | White Uniformity | 1.33/1.43 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 52% | sRGB | 72% coverage |
| Adobe RGB | 54% coverage | DCI-P3 | 54% coverage | |
| Rec.2020 | 39% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
Chimei Innolux ZJ050NA-05B Interface Details
| Signal Electrical : | Voltage Supply | 1.8/3.3V (Typ.)(AVDD/DVDD) | Current Supply | 0.17/18.4mA (Typ.)(AIDD/DIDD) | ||
|---|---|---|---|---|---|---|
| Consumption | 61mW (Typ.) | |||||
| Signal Type : | Parallel RGB (1 ch, 8-bit) | Signal Voltage | 0≤VIL≤0.2DVDD; 0.8DVDD≤VIH≤DVDD | |||
| Interface Features : | Position | - | Type | FPC | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| 1 pcs | 67 pins | 0.3 mm | ||||
Chimei Innolux ZJ050NA-05B Backlight Details
| Backlight Features: | Shape | Array | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | 6S2P | Life Time | 20K(Min.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 18.6/19.8/21.0V (Min./Typ./Max.) | Current Supply | 40±4.0mA | ||
| Consumption | 0.79W (Typ.) | |||||
| Interface Features : | Position | - | Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
