China LC650EGE-FKM1 LG Display 65
China LC650EGE-FKM1 LG Display 65
China LC650EGE-FKM1 LG Display 65

LC650EGE-FKM1 LG Display 65" 3840(3)×2160 500 cd/m² INDUSTRIAL LCD DISPLAY

Price Negotiable
Price: 60USD
MOQ: 1PCS
Delivery Time: 1-2 DAYS
Brand: LG Display
Product Description

LG Display LC650EGE-FKM1 Application Details

Basic Info :
Panel Brand

LC650EGE-FKM1Panel Model
Diagonal Size
65"
Application

a-Si TFT-LCD , LCMPanel Type
Model Alias
LC650EGE (FK)(M1)
Reliability :
Operating Temp.
0 ~ 50 °C
Storage Temp.
-20 ~ 60 °C



LG Display LC650EGE-FKM1 Mechanical Details

Pixel Features :
Pixel Format
3840(3)×2160, UHD
Dot Pitch
0.124×0.372 mm (H×V)
Configuration
RGBW Vertical Stripe
Pixel Pitch
0.372×0.372 mm (H×V) [68PPI]
Mechanical Size :
Display Area
1428.48×803.52 mm (H×V)
Bezel Area
1433.4×808.1 mm (H×V)
Outline Dim.
1450.6×833.366 mm (H×V)
Outline Depth
15.17 (Typ.) mm
Outline Features :
Form Factor
Flat Rectangle
Orientation
Landscape type
Aspect Ratio
16:9 (H:V)
Shape Style

Other Features :
Weight
18.2/19.1Kgs (Typ./Max.)
Surface
Antiglare (Haze 3%), Hard coating (3H)



LG Display LC650EGE-FKM1 Optical Details

Basic Information :
Brightness
500 cd/m² (Typ.)
Contrast Ratio
1200:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Min.)(CR≥10)
Optical Mode
IPS, Normally Black, Transmissive
Viewing Direction
Symmetry
Response Time
8 (Typ.)(G to G) ms
Color Performance :
Chromaticity
Wx:0.281; Wy:0.288
Color Numbers
1.07B (8-bit + Dithering)
Color Temperature
9966K
Uniformity
1.54 (Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
81%
sRGB
100% coverage
Adobe RGB
78% coverage
DCI-P3
83% coverage
Rec.2020
61% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



LG Display LC650EGE-FKM1 Backlight Details

Back-light Features :
Lamp Type
WLED
Amount
-
Life Time
30K(Min.) (Hours)
Replacement
-
Lamp Shape
-
Position
Edge light type
Lamp Electrical :
Voltage Input
135.8/140.6/150.7V (Min./Typ./Max.)
Current Input
120±6mA
Consumption
101.2/113.9W (Typ./Max.)
Interface Features :
Type
Connector
Position
-
Lamp Driver
No
Interface Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration
UJU
HS100-L08N-N62
1.0 mm
8 pins
1 pcs
BLE-8PINS-CCCNNNNA
UJU
HS100-L08N-N62-A
1.0 mm
8 pins
1 pcs
BLE-8PINS-ANNNNCCC



LG Display LC650EGE-FKM1 Interface Detail

Signal Systerm :
V-by-One 8 lane
Logic Voltage
-
Signal Electrical :
Voltage Input
12.0V (Typ.)
Current Input
1.21/1.57A (Typ./Max.)
Consumption
14.5/18.9W (Typ./Max.)
Interface Features :
Type
Connector
Position
Connector Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration
JAE
FI-RXE51S-HF
0.5 mm
51 pins
1 pcs




LG Display LC650EGE-FKM1 Carton Details

Package Carton : Amount Net Weight Carton Size (L×W×H)
16 pcs / box - 1600×1140×1053 mm

 FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
