LD490EQG-FNA1 LG Display 49" 3840×2160 700cd/m2 INDUSTRIAL LCD DISPLAY

Price Negotiable
Price: Negotiable
MOQ: 1PCS
Delivery Time: 1-2 DAYS
Brand: LG Display
Product Description

LG Display LD490EQG-FNA1 Application Details

Basic Information :
Brand

LD490EQG-FNA1Model
Type
a-Si TFT-LCD , LCM
Used For

Screen Size
49 inch
Alias
LD490EQG (FN)(A1)
Environment :
Storage Temp.
-20 ~ 60 °C
Operating Temp.
0 ~ 50 °C



LG Display LD490EQG-FNA1 Mechanical Details

Pixel Features :
Resolution
3840(RGB)×2160, UHD
Dot Pitch(mm)
0.09321×0.27963 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.27963×0.27963 (H×V) [90PPI]
Mechanical Size :
Active Area(mm)
1073.8(H) × 604(V)
Bezel Area(mm)
1078.8(H) × 609(V)
Outline Dim.(mm)
1098.6(H) × 633.3(V)
Depth(mm)
19.4/27.0 (Typ./Max.)
Outline Features :
Form Style
Flat Rectangle
Shape Style

Aspect Ratio
16:9 (H:V)
Orientation
Landscape / Portrait
Other Spec :
Weight
12.0/13.2Kgs (Typ./Max.)
Treatment
Antiglare (Haze 3%), Hard coating (2H)



LG Display LD490EQG-FNA1 Optical Details

Basic Information :
Luminance(cd/m²)
700 (Typ.)
Contrast Ratio
1100:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Min.)(CR≥10)
Display Mode
IPS, Normally Black, Transmissive
Best View on
Symmetry
Response(ms)
13/12 (Typ.)(Tr/Td)
Color Performance :
White Coordinate
Wx:0.279; Wy:0.292
Display Colors
1.07B (10-bit)
Color Temperature
9972K
White Uniformity
1.54 (Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
70%
sRGB
94% coverage
Adobe RGB
72% coverage
DCI-P3
72% coverage
Rec.2020
52% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance :
Outdoor Visibility
Sunlight Readable
Transmissivity
-



LG Display LD490EQG-FNA1 Interface Detail

Signal Electrical :
Voltage Supply
12.0V (Typ.)
Current Supply
1.13/1.47A (Typ./Max.)
Consumption
13.6/27.5W (Typ./Max.)
Signal Type :
EPI
Logic Voltage
-
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Quantity
Pin Configuration



68 pins
2 pcs




LG Display LD490EQG-FNA1 Backlight Details

Backlight Features :
Type
WLED
Quantity
-
Position
Edge light type
Replacement
-
Shape
-
Life Time
50K(Min.) (Hours)
Lamp Electrical :
Voltage Supply
132.4±6.6V
Current Supply
100mA (Typ.)
Consumption
75.5/79.2W (Typ./Max.)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Quantity
Pin Configuration
UJU
HS100-L08N-N62
1.0 mm
8 pins
1 pcs
BLE-8PINS-CCCNNNNA
UJU
HS100-L08N-N62-A
1.0 mm
8 pins
1 pcs
BLE-8PINS-ANNNNCCC
Backlight Driver :
No





LG Display LD490EQG-FNA1 Packing Details

Package Box : Quantity Weight Box Size
18 pcs / box - 1300×1140×930 mm (L×W×H)
