65" 3840x2160 Square Tft Display 400cd/M2 LC650EQF-DKM1 89/89/89/89 (Typ.)(CR≥10)
Price:
Negotiable
MOQ:
1PCS
Delivery Time:
1-2 DAYS
Brand:
LG DISPLAY
Product Description
LG Display LC650EQF-DKM1 Application Details
| Basic Info : | Panel Brand | Panel Model | LC650EQF-DKM1 | |
|---|---|---|---|---|
| Diagonal Size | 65" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | LC650EQF (DK)(M1) | |
| Reliability : | Operating Temp. | 0 ~ 50 °C | Storage Temp. | -20 ~ 60 °C |
LG Display LC650EQF-DKM1 Mechanical Details
| Pixel Features : | Pixel Format | 3840(RGB)×2160 [UHD] | Dot Pitch | 0.124×0.372 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.372×0.372 mm (H×V) [68PPI] | |
| Mechanical Size : | Display Area | 1428.48×803.52 mm (H×V) | Bezel Area | - |
| Outline Dim. | 1452.1×827.83 mm (H×V) | Outline Depth | 10.4 (Typ.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 16:9 (H:V) | Shape Style | ||
| Other Features : | Weight | 20.8/21.9Kgs (Typ./Max.) | Surface | Antiglare (Haze 3%), Hard coating (2H) |
LG Display LC650EQF-DKM1 Optical Details
| Basic Information : | Brightness | 400 cd/m² (Typ.) | Contrast Ratio | 1400:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Optical Mode | IPS, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 5 (Typ.)(G to G); 8 (Typ.)(MPRT) (ms) | |
| Color Performance : | Chromaticity | Wx:0.281; Wy:0.288 | Color Numbers | 16.7M/1.07B (8-bit / 8-bit + Dithering) |
| Color Temperature | 9966K | White Uniformity | 1.54 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 84% | sRGB | 99% coverage |
| Adobe RGB | 78% coverage | DCI-P3 | 84% coverage | |
| Rec.2020 | 63% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
LG Display LC650EQF-DKM1 Backlight Details
| Back-light Features: | Lamp Shape | - | Lamp Type | WLED | Life Time | 30K(Min.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | - | Position | Edge light type | |
| Lamp Electrical : | Voltage Input | 118.8/128.5/139.3V (Min./Typ./Max.) | Current Input | 80±4mA | ||
| Consumption | 123.4/133.7W (Typ./Max.) | |||||
| Interface Features : | Type | Connector | Position | - | Lamp Driver | No |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| UJU | HS100-L08N-N62 | 1.0 mm | 8 pins | 1 pcs | ||
| UJU | HS100-L08N-N62-A | 1.0 mm | 8 pins | 1 pcs | ||
LG Display LC650EQF-DKM1 Interface Details
| Signal Systerm : | V-by-One 16 lane | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 12.0V (Typ.) | Current Input | 0.85/1.1A (Typ./Max.) | ||
| Consumption | 10.19/13.25W (Typ./Max.) | |||||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| JAE | FI-RE51S-HF | 0.5 mm | 51 pins | 1 pcs | ||
| JAE | FI-RE41S-HF | 0.5 mm | 41 pins | 1 pcs | ||
LG Display LC650EQF-DKM1 Carton Details
| Package Carton : | Amount | Net Weight | Carton Size (L×W×H) |
|---|---|---|---|
| 18 pcs / box | - | 1700×1140×1100 mm |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
