China FHD 40PPI 55in TFT LCD Panel 500cd/M2 LD550DUN-THB8 89/89/89/89 (Typ.)(CR≥10) for sale
China FHD 40PPI 55in TFT LCD Panel 500cd/M2 LD550DUN-THB8 89/89/89/89 (Typ.)(CR≥10) for sale
China FHD 40PPI 55in TFT LCD Panel 500cd/M2 LD550DUN-THB8 89/89/89/89 (Typ.)(CR≥10) for sale
China FHD 40PPI 55in TFT LCD Panel 500cd/M2 LD550DUN-THB8 89/89/89/89 (Typ.)(CR≥10) for sale

FHD 40PPI 55in TFT LCD Panel 500cd/M2 LD550DUN-THB8 89/89/89/89 (Typ.)(CR≥10)

Price Negotiable
Price: Negotiable
MOQ: 1PCS
Delivery Time: 1-2 DAYS
Brand: LG DISPLAY
Product Description

LG Display LD550DUN-THB8 Application Details

Basic Detail :
Manufacturer

LD550DUN-THB8Model Name
Panel Type
a-Si TFT-LCD , LCM
Another Name
LD550DUN (TH)(B8)
Panel Size
55 inch
Designed For
Maximum Ratings :
OP Temperature
0 ~ 50 °C
ST Temperature
-20 ~ 60 °C



LG Display LD550DUN-THB8 Optical Details

Basic Detail :
Luminance
500 cd/m² (Typ.)
Contrast Ratio
1400:1 (Typ.) (Transmissive)
Good View at
Symmetry
Response Speed
8 (Typ.)(G to G) ms
Viewing Angle
89/89/89/89 (Min.)(CR≥10)
Operating Mode
S-IPS, Normally Black, Transmissive
Color Performance :
Chromaticity
Wx:0.279; Wy:0.292
Support Color
1.06B (8-bit + Dithering)
Color Temperature
9972K
White Variation
1.11/1.25 (Typ./Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
72%
sRGB
99% coverage
Adobe RGB
75% coverage
DCI-P3
75% coverage
Rec.2020
54% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



LG Display LD550DUN-THB8 Interface Detail

Signal Electrical :
Input Current
0.83/1.08A (Typ./Max.)
Input Voltage
12.0V (Typ.)
Consumption
10.0/13.0W (Typ./Max.)
Signal Interface
LVDS (2 ch, 10-bit)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
JAE
FI-RE51S-HF
0.5 mm
51 pins
1 pcs



LG Display LD550DUN-THB8 Lightting Details

Lamp Features :
Lamp Type
WLED
Amount
-
Position
Direct light type
Exchange
-
Lamp Shape
-
Lamp Life
60K(Typ.) (Hours)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
YEONHO
20022WR-14B2
2.0 mm
14 pins
1 pcs

YEONHO
20022WR-12B2
2.0 mm
12 pins
1 pcs

Backlight Driver :
With LED Driver
Driver Electrical :
Input Voltage
24.0±2.4V
Input Current
6.1/6.9A (Typ./Max.)
Consumption
146.4/165.6W (Typ./Max.)



LG Display LD550DUN-THB8 Packing Details

Package Box : Amount Size (L×W×H) Weight
10 pcs / box - 1440×1140×950 mm



 Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
