LC420DUH-FGP2 LG Display 42" 1920(RGB)×1080 300 cd/m² INDUSTRIAL LCD DISPLAY
Price:
Negotiable
MOQ:
1PCS
Delivery Time:
1-2 DAYS
Brand:
LG DISPLAY
Product Description
LG Display LC420DUH-FGP2 Application Features
| Basic Information : | Brand | Model | Type | Model Alias |
|---|---|---|---|---|
| LC420DUH-FGP2 | a-Si TFT-LCD , LCM | LC420DUH (FG)(P2) | ||
| Reliability : | RoHS | Operating Temperature | Storage Temperature | Vibration Resistance |
| 0 ~ 50 °C | -20 ~ 60 °C |
LG Display LC420DUH-FGP2 Mechanical Features
| Panel Size : | 42 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 1920(RGB)×1080, FHD | RGB Vertical Stripe | 0.1611×0.4833 mm | 0.4833×0.4833 mm [52PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 927.94×521.96 mm | 933.0×527.0 mm | 959.55×559.5 mm | 25/35 (Typ./Max.) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | 16:9 (W : H) | Landscape type | ||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 6.00/8.00Kgs (Typ./Max.) | Antiglare (Haze 1%), Hard coating (2H) | ||
LG Display LC420DUH-FGP2 Optical Features
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 300 cd/m² (Typ.) | IPS, Normally Black, Transmissive | 1200:1 (Typ.) (Transmissive) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 89/89/89/89 (Min.)(CR≥10) | Symmetry | 6/8 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Temperature | Color Amount | White color Chromaticity |
| 9969K | 16.7M (8-bit) | X:0.280; Y:0.290 | |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 70% | 97% | 72% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 73% | 52% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Luminance Variation : | 1.54 (Max.)(9 points) | ||
| Performance : | 3D Type | Outdoor Visibility | Reflectance |
| 3D (Polarizer Glass) | No | ||
LG Display LC420DUH-FGP2 Interface Features
| Signal Electrical : | Current Input | Voltage Input | Consumption | |||
|---|---|---|---|---|---|---|
| 350/460mA (Typ./Max.) | 12.0V (Typ.) | 4.2/5.5W (Typ./Max.) | ||||
| Interface Features : | Position | Type | Interface | |||
| - | Connector | EPI | ||||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| HRS | TF06L-50S-0.5SH | 2 pcs | 0.5 mm | 50 pins | ||
LG Display LC420DUH-FGP2 Backlight Features
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| WLED | Direct light type | - | - | 30K(Min.) | - | |
| WLED Electrical : | Current Input | Voltage Input | Consumption | |||
| 190mA (Typ.) | 186.9/202.2/221.1V (Min./Typ./Max.) | 38.4W (Typ.) | ||||
| Interface Features : | Position | Type | WLED Driver | |||
| - | Connector | No | ||||
| Interface Detail | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| YEONHO | SMH200-07 | 1 pcs | 2.0 mm | 7 pins | BLE-7PINS-CNNNNNA | |
LG Display LC420DUH-FGP2 Packing Features
| Package Carton : | Amount | Weight | Carton Size |
|---|---|---|---|
| 22 pcs / box | - | 1300×1140×772 mm (L×W×H) |
