0.84W 6.0" 720x1280 TFT LCD Panel 450cd/m2 247PPI HSD060CHW1-A00 HannStar
Price:
Negotiable
MOQ:
1PS
Delivery Time:
1-3days
Brand:
HannStar
Product Description
HannStar HSD060CHW1-A00 Application Features
| Basic Information : | Manufacturer | Panel Model | Panel Type | Alias |
|---|---|---|---|---|
| HSD060CHW1-A00 | a-Si TFT-LCD , LCM | - | ||
| Environment : | RoHS State | Operating Temp. | Storage Temp. | Vibration Level |
| -20 ~ 70 °C | -30 ~ 80 °C |
HannStar HSD060CHW1-A00 Optical Features
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
|---|---|---|---|
| 450 (Typ.) | 89/89/89/89 (Typ.)(CR≥10) | 22 (Typ.)(Tr+Td) | |
| Best View on | Display Mode | Contrast Ratio | |
| Symmetry | IPS Pro, Normally Black, Transmissive | 1000 : 1 (Typ.) (Transmissive) | |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| 6485K | 16.7M (8-bit) | X:0.313; Y:0.329 | |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 68% | 94% | 71% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 71% | 51% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| White Variation : | 1.25 (Max.)(9 points) | ||
HannStar HSD060CHW1-A00 Mechanical Features
| Panel Size : | 6.0" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
| 720(RGB)×1280 [WXGA] | RGB Vertical Stripe | 0.10275×0.10275 [247PPI] | 0.03425×0.10275 | |
| Mechanical Size : | Active Area (mm) | Bezel Area (mm) | Outline Dimension (mm) | Outline Depth (mm) |
| 73.98(H) × 131.52(V) | - | 77.4(H) × 140(V) | 1.65/2.55 (Typ./Max.) mm | |
| Outline Features : | Form Factor | Orientation | Aspect Ratio | Shape Style |
| Flat Rectangle | Portrait type | 9:16 (H:V) | ||
| Other Detail : | Weight | Panel Cover | Treatment | |
| 38.5/42.0g (Typ./Max.) | - | Hard coating (3H) | ||
HannStar HSD060CHW1-A00 Backlight Features
| Lamp Features: | Type | Position | Quantity | Shape | Life(Hours) | Lamp Exchange |
|---|---|---|---|---|---|---|
| WLED | Edge light type | 7S2P | Array | 15K(Min.) | - | |
| WLED Electrical : | Voltage Supply | Current Supply | Power | |||
| 21.0V (Max.) | 40mA (Typ.) | 0.84W (Max.) | ||||
| Interface Features : | Position | Backlight Driver | Type | |||
| - | No | |||||
HannStar HSD060CHW1-A00 Interface Features
| Panel Driving Electrical : | Voltage Supply | Current Supply | Power | |||
|---|---|---|---|---|---|---|
| 1.8/2.8V (Typ.)(IOVCC/VCC) | 16/29mA (Typ.)(IOICC/ICC) | - | ||||
| Interface Features : | Position | Signal | Type | |||
| - | MIPI (4 data lanes) | FPC | ||||
| FPC Detail : | Brand | Model | Pin Pitch | Pin Amount | Quantity | Configuration |
| 0.3 mm | 27 pins | 1 pcs | ||||
HannStar HSD060CHW1-A00 Packing Features
| Package Box : | Quantity | Weight | Box Size |
|---|---|---|---|
| 80 pcs / box | - |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
