Folding Boom Marine Crane Customer Design 2T@6M Hydraulic Telescopic Pedestal Crane
Product Description
These cranes are suitable when the deck space is limited.
Their design combines maximum performances with flexible working operations. These cranes are handy and allow comfortable working operations in all operative conditions.
They are designed and manufactured in conformity with the current Marine Rules and they can be customized on request.
Advantages of this knuckle and telescopic boom ccstal crane
Running smoothly.
Rates of speed can be changed.
360 degrees rotary.
Both electro hydraulic and manual to control.
Operate conveniently.
Safety and reliability.
Product Feature
1.Easy maintenance at all situation.
2.Self contained unit with integrated hydraulic power pack.
3.Fail-safe brakes on all movements.
4.Fully enclosed and equipped operator cabin with air condition.
5.The variable speed hoist will automatically adjust to the highest possible speed for the appropriate load.
6.Technology from Germany.
7.Base on many year's design and fabrication experience of crane and other similar equipment.
8.Suitable for all kinds of ships and low power consumption and high efficiency.
9.Welded and high strength box boom for easy maintenance.
10.With Many safety protection devices---hook up limiter and overload limiter, emergency stop button.
Technical Parameters
| SWL | 2T6M |
| Max. Working Radius | 6 m |
| Min. Working Radius | 1.25 m |
| Slewing Speed | 0~1 r/min |
| Hoisting Speed | 0~15 m/min |
| Slewing Angle | 360° |
| Luffing Time | ~45 s |
| Extension Time | ~20 s |
General Arrangement
Product Details
Customer Bulid
OUCO factory specializes in crane field for more than 10 years. OUCO can design and manufacture any type marine/offshore cranes based on buyer's required specifications.
| Brand | OUCO |
| Spare parts | 1 set ( If needed, more spare parts are available to be provided according to customers' requirements ) |
| Warranty | 1 year( If needed, warranty time is available to be extended according to customers' requirements ) |
Our Certification
Our Service
Once Cooperation Be Friends Forever
Our company participates in various exhibitions every year and presents our products to partners and customers around the world.
We have our own factory and welcome friends from all over the world to visit us.Once Cooperation Be Friends Forever.
FAQ
1. Q:Can this type work in hazardous environment?
A:Sure! We can customize for you, acid proof or explosion proof, no problem for that.
2. Q:Can you provide the serious lifting tools?
A:Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
3.Q: How can we install the crane?
A:Our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit your country.
4. Q:Safety device
A:Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
