Overhead Bare Conductor Almelec Cable ASTER 228 288mm2 AAAC Conductor NFC 34-125 For Transmission And Distribution
Description
b. Good conductivity, Resistance chemical corrosion and heat-ageing, environment stress.
c. Unit volume light, Simple in structure.
d. Convenient to use, especially for laying across rivers and valleys where special geographical terrain exists.
| Code Name | Stranding | Section | Overall Diameter | Conductor Weight | Rated strength | Electrical Resistance | |
| No. | mm | mm2 | mm | kg/km | kN | DC.20℃ | |
| Ω/km | |||||||
| ASTER 22 | 7 | 2 | 21.99 | 6 | 60.2 | 7.1 | 1.5 |
| ASTER 34.4 | 7 | 2.5 | 34.36 | 7.5 | 94 | 11.15 | 0.958 |
| ASTER 54.6 | 7 | 3.15 | 54.55 | 9.45 | 149 | 17.55 | 0.603 |
| ASTER 75.5 | 19 | 2.25 | 75.54 | 11.25 | 208 | 24.3 | 0.438 |
| ASTER 93.3 | 19 | 2.5 | 93.27 | 12.5 | 257 | 30 | 0.354 |
| ASTER 117 | 19 | 2.8 | 116.98 | 14 | 322 | 37.65 | 0.283 |
| ASTER 148 | 19 | 3.15 | 148.01 | 15.75 | 407 | 47.65 | 0.224 |
| ASTER 181.6 | 37 | 2.5 | 181.62 | 17.5 | 500 | 58.45 | 0.183 |
| ASTER 228 | 37 | 2.8 | 227.83 | 19.6 | 627 | 73.4 | 0.146 |
| ASTER 288 | 37 | 3.15 | 288.34 | 22.05 | 794 | 92.8 | 0.115 |
| ASTER 366 | 37 | 3.55 | 366.22 | 24.85 | 1009 | 117.85 | 0.0905 |
| ASTER 570 | 61 | 3.45 | 570.22 | 31.05 | 1574 | 183.6 | 0.0583 |
| ASTER 851 | 91 | 3.45 | 850.66 | 37.95 | 2354 | 273.9 | 0.0391 |
| ASTER 1144 | 91 | 4 | 1143.51 | 44 | 3164 | 362.6 | 0.0292 |
| ASTER 1600 | 127 | 4 | 1595.93 | 52 | 4425 | 506.4 | 0.0206 |
Why you choose us?
- Products comply with GB, IEC, BS, ASTM, DIN, VDE, and JIS standards; Customer standard requirements accepted;
- Certified to ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007;
- Registered capital of $30 million and factory covers an area of 60,000㎡;
- Advanced test equipment and procedures, 100% inspection before factory;
- Enough stocks and the higest efficient shipping time guarranteed;
