0.6/1KV Low Voltage PVC Insulated PVC Sheathed Unarmored Cable CU/PVC/PVC 1x500sqmm NYY Cable IEC60502-1

Name: 0.6/1KV Low Voltage PVC Insulated PVC Sheathed Unarmored Cable CU/PVC/PVC 1x500sqmm NYY Cable IEC60502-1
Brand: Zhenglan Cable Technology Co., Ltd

Price Negotiable

Price: 0.3USD-2USD/m

MOQ: 500 meters

Delivery Time: 7-10 working days

Brand: Zhenglan cable

Product Description

Applications

Can be used universally for connecting the power supply in buildings and industrial facilities.
Suitable for energy distribution in power and converter stations.
Suitable for use in AC and DC charging infrastructures for electromobility.
For fixed installation in water, air, earth and concrete. In the ground, the minimum installation depth without additional, suitable protection is 0.6 m, and at least 0.8 m under roads.
Can be used in dry, damp or wet environments.
Suitable for medium mechanical stress.
Suitable for outdoor use, subject to the temperature range.

Model NO.

NYY

Application

Underground

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Electricity Supply in Low Voltage System

Certification

ISO9001, CE, CCC

Brand

Zhenglan Cable

Rated Voltage

0.6/1 Kv

Number of Core

1

Refer Standard

IEC 60502-1

Class of Conductor

2

Transport Package

Wooden Drum/Steel Drum

Specification

500 mm2

Trademark

Zhenglan Cable

Origin

Jiaozuo, Henan, China

HS Code

8544492100

Production Capacity

2000km/Month

Dimensions and Weights				Electrical Information
Nominal cross-section	Overall Diameter	Net Weight	Delivery reel size for 1000m cable	Conductor DC (max.) resistance at 20 °C (max.)	Current carrying capacity in
					Ground(A)		Air(A)
mm²	mm	kg/km	cm	ohm/km	•••		•••
1x500 rm	38,0	5150	210	0,0366	823	698	940	749
