N2XBY NA2XBY Steel Tape Armoured Cable 0.6/1kV With Copper / Aluimum Conductor (CU/PVC/XLPE/LSZH/STA/NYBY/NAYBY）
0.6/1kV Copper(Al) Conductor, XLPE Insulated, Steel Tape Armoured, PVC Sheathed Power Cable(N2XBY/NA2XBY)
PVC Sheathed Power Cable Application
Laying in the room, tunnels, cable trenches and pipes, can also be buried in loose soil. To be laid underground, the cable could bear certain mechanical force, but it couldn't bear great pulling force. Used for power station, industry, switchgear and urban power supply network.
PVC Sheathed Power Cable Standards
Basic design to IEC 60502-1, IEC 60228
China: GB/T 12706.2-2008
Other standards such as BS7870,DIN and ICEA upon request
PVC Sheathed Power Cable Characteristics:
XLPE insulated power cable features mechanical strength, aging, environmental stress and chemical resistance, available for working under high temperature condition for long.
PVC Sheathed Power Cable Electrical Properties:
| Rated Voltage Uo/U (Um) | 600/1000V, BS5467 |
| Installation Temperature | Minimum: 0°C,Maximum: 60°C |
| Installation Type | Outdoor Direct burial |
| Operating Temperature | Maximum: 90°C. |
| Short-circuit Maximum Conductor Temperature: | 250°C. |
| Min. Bending Radius | 12 x cable O.D for multi-core armoured cables |
PVC Sheathed Power Cable Packing Details:
1. standard seaworthy drum (wooden drum,wooden steel drum, steel drum) are available;
2. drum size can be customized or meeting container the Max.load size;
3. drum overall diameter can be from 1 meter to 2.5 meters;
4. under customer requirement with certain length packed in rolls wrapped in plastic tape or Nylon plastic tape.
Construction Parameters:
IEC 60502-1
| Nominal Cross Section of Conductor | Nominal Diameter of Conductor | Nominal Thickness of Insulation | Nominal Thickness of Copper Tape Screen | Nominal Thickness of Inner Sheath | Nominal Thickness of Steel Tape Armouring | Nominal Thickness of PVC Sheath | Approx. Overall Diameter | Approx. Weight | |
| Al Conductor | Cu Conductor | ||||||||
| No. X mm2 | mm | mm | mm | mm | mm | mm | mm | kg/m | kg/m |
| 3 X 25 | 6.0 | 3.4 | 0.1 | 1.3 | 0.5 | 2.0 | 43.4 | 2.16 | 2.61 |
| 3 X 35 | 6.9 | 3.4 | 0.1 | 1.3 | 0.5 | 2.0 | 45.4 | 2.36 | 2.99 |
| 3 X50 | 8.2 | 3.4 | 0.1 | 1.4 | 0.5 | 2.2 | 48.8 | 2.69 | 3.54 |
| 3 X 70 | 9.7 | 3.4 | 0.1 | 1.5 | 0.5 | 2.3 | 52.4 | 3.10 | 4.33 |
| 3 X 95 | 11.3 | 3.4 | 0.1 | 1.5 | 0.5 | 2.4 | 56.1 | 3.56 | 5.26 |
| 3 X 120 | 12.8 | 3.4 | 0.1 | 1.5 | 0.5 | 2.5 | 59.5 | 4.04 | 6.19 |
| 3 X 150 | 14.2 | 3.4 | 0.1 | 1.5 | 0.5 | 2.6 | 62.7 | 4.49 | 7.19 |
| 3 X 185 | 15.9 | 3.4 | 0.1 | 1.6 | 0.5 | 2.6 | 66.6 | 5.12 | 8.49 |
| 3 X 240 | 18.3 | 3.4 | 0.1 | 1.7 | 0.5 | 2.8 | 72.4 | 5.99 | 10.42 |
| 3 X 300 | 20.4 | 3.4 | 0.1 | 1.8 | 0.5 | 3.0 | 77.5 | 6.86 | 12.42 |
| 3 X 400 | 23.2 | 3.4 | 0.1 | 1.9 | 0.8 | 3.2 | 85.4 | 8.97 | 16.05 |
