Warehouse Heat Insulated PVC Corrugated Roof Tiles Sheet Extrusion Machine

Warehouse Heat Insulated PVC Corrugated Roof Tiles Sheet Extrusion Machine​

Production Description :

PVC corrugated sheet line is specially designed for PVC corrugated sheet line , it is a kind of composite materials adopt the plastic film after color printing and cold rolled sheet combined with(melting or bonding),which is to replace the traditional printing on mental plates.Adopt plastic film(PET,PP,PE) combined with metal plate through hot melting or bonding,which has solved the corrosivity of metal plate and metal container,both has the decorating,barrier of plastic film and the malleability, figurability of metal.

Extruder: Single screw extruder PMMA ASA, conical twin screw extruder PVC.

T-Die Head: The hanger-type flow structure, a suitable compression ratio to ensure the stability of material flow evenly.

Calibrating molds: rational design, the unique design of the coolingflow to ensure the accuracy of products.

Hauling machine: roller traction, using high quality NBR rubber roller, pneumatic adjustment, and frequency speed adjustment..

Cutting Machine: Knife cutting, fast, good accuracy.

Specifications

1. Usual sheet width: 880-1150mm
2. Usual sheet thickness: 1-4MM
