45 Degree Cut Batten Roll Forming Machine For Inner Roof Decoration Batten Roof Top Hat Panel With Auto Stacking
Price:
negotiable
MOQ:
1
Delivery Time:
90 WORKING DAYS
Brand:
NKH ROLL FORMING MC
Product Description
YX38-40 Roll Forming Machinery For Inner Roof Decoration, Batten roof, Top hat panel
Machine’s Components:
| 3tons Hydraulic un-coiler | 1set |
| Roll Forming System | 1set |
| Hydraulic Cutting Machine | 1set |
| Hydraulic Station | 1set |
| PLC Control Cabinet | 1set |
| Stacking Machine |
1set |
Working Flow of Roll Forming Machine:
Uncoiling the sheet---Guiding the sheet---Roll forming---Cutting the panel---Auto stacking
Technical Parameter:
| No. | item | Parameter(all is subject to our final design) | |
|
1
|
Suitable raw material | Type | Common galvanized & pre-painted steel |
| Yield strength | 550MPa(or other high strength steel) | ||
| Thickness(mm) | 0.4-0.8 | ||
| 2 | Manual uncoiler’s capacity | Max.3tons | |
| 3 | Forming speed(m/min) | About 20-25m/min | |
| 4 | Main motor power(KW) | 7.5kw | |
| 5 | Hydraulic power(KW) | 4kw | |
| 6 | Forming roller groups | Around 12-14 groups | |
| 7 | Raw material of forming roller | High quality No.45 steel | |
| 8 | Raw material of cutting blade | Cr12 with heat treatment | |
| 9 | controlling system | Siemens PLC & touch screen | |
| 10 | Suitable industrial voltage | According to your special requirement | |
