12V 480Ah Electric Vehicle Battery Pack , LIFEPO4 Battery Pack Power Supply

Price Negotiable
Price: Negotiable
MOQ: 5 PACK
Delivery Time: 15 days
Brand: VICT
Product Description

12V 480Ah Electric Vehicle Battery Pack , LiFePO4 Battery Power Supply



Specifications

Model No VS12480LFP
Rated Voltage 12.8V
Rated Capacity 480Ah
Cell Type LiFePO4 3.2V 120Ah
Configuration 4S2P
Full Charged Voltage 14.6V (3.65V per cell)
Charge Cut-off Voltage 15.6V (3.9V per cell)
Discharge C ut-offVoltage 8V (2.0V per cell)
Standard Charge Current 0.2C-0.5C
Max Charge Current 1C
Continuous Discharge Current 120A
Peak Discharge Current 240A
Weight 14.76kg
Size 406*170*206 mm
Operating Temperature Charging: 0°C ~ 45°C
Discharging: -20°C ~ 55°C
Storage Temperature Recommended to store 20 ± 5°C for long time storage
Cycle Life 3000 cycles (80% of initial capacity at 0.2C rate)



Quality and Guarantee



a)  Our lithium batteries follows the ISO9001, CE, RoHS international standard in various aspects from material preparation to production, quality  control, sales, transportation, customers service.

b)  Power management: You may be completely confident in our lithium batteries because all batteries have built in high quality PCB board, charging protectors, thermal protectors and circuit breakers, which effectively avoid the problems of over discharge, ove charge, over heating and short circuit etc.

c)  For each batch batteries, safe test such as nail penetration test would be conducted to assure safety.

d)  Full capacity is assured due to capacity test woud be carried out for each pieces.

e)  Safety test, after nail penetration test with fully charging, there is no fire, no explosion.



Lithium Phosphate Ion Battery Advantages

  • Advanced lithium ferro phosphate
  • No cobalt – no toxicity – no hazards
  • 98% efficient
  • Long cycle life 4500 remain above 85%.
  • Low self discharge,less than 3%
  • Ultra safe
  • Excellent Temperature resilience-ambient temperatures up to 50°C will not affect the life.
  • Lighter and smaller than lead acid battery
  • Environment friendly, Maintenance free,there is no memory effect.
  • Can be charged using most standard chargers of lead-acid battery



Packaging Photos



Attention

  1.  Do not immerse the battery in water or allow it.
  2. Do not use any chargers other than those recommended.
  3. Do not reverse the positive(+) and negative(-) terminals.
  4. Do not put the battery into a fire or apply direct heat to it.
  5. Do not short-circuit the battery by connecting wires or other metal objects to the positive(+) and negative(-) terminals.



Application
