Aqua Female 24F MPO Fiber Optic Cable Round 3.0mm 5M Breakout Patch Cord
Aqua Female 24F MPO Fiber Optic Cable Round 3.0mm 5M Breakout Patch cord
Description:
Aqua OM3 24F MPO Female-20xLC/PC Round 3.0mm 5M Breakout Patch cord manufactured by ANC International Co., Limited provides connections between single CFP/CXP (100G transceiver with MPO interface) and 10 x SFP+ (10G transceivers with LC Duplex Interface). MPO MTP Breakout Patch cord allows the redistribution of various optical fibers to individual devices without additional networking equipment. ANC MPO harness patch cords reduce the overall cost and setup time for complex high density networking and are widely used in data center, telecom and backbone application for 100G connectivity. 100G parallel optics transceivers (100GBASE-XR10) can support 10x10G modes. This feature allows new parallel optics active equipment being compatible with existing 10G transceivers.
ANC offer a wide range of MPO MTP Patch cords including Trunk Cables, MTP to LC breakout cables and MTP cassettes (or patch panels). All the assemblies are fully compliant with IEC Standards 61754-7 and TIA 604-5. We also provide Customized productions on optional fiber counts, cable types and lengths etc.
Features:
Low Insertion Loss & High Reflection Performance
Complied to IEC Standards 61754-7 and TIA 604-5.
High-quality MPO connectors
100% 3D interferometer Pass
100% factory tested before shipping
Used to connector 100G CFP, CXP to SFP+ transceiver;
Applications:
Data Center
100G CFP to SFP+ Connection
100G CXP to SFP+ Connection
100G to 10x 10G Connection
Optical Performance:
| MPO/MTP | SM Standard | SM Low Loss | MM Standard | MM Low Loss | |
| Insertion Loss | Typical | 0.35dB | 0.20dB | 0.35dB | 0.20dB |
| Max | 0.75dB | 0.35dB | 0.65dB | 0.35dB | |
| Return Loss | APC≧50dB | ≧25dB | ≧35dB | ||
| PC≧40dB | |||||
| Durability | ≤0.3dB (change 500matings) | ≤0.3dB (change 1000matings) | |||
| Exchangeability | ≤0.3dB (Connector randomly) | ||||
| Tensile Strength | ≤0.3dB (Max 66N) | ||||
| Vibration | ≤0.3dB (10~55Hz) | ||||
| Operation Temperature | -40℃ ~ +75℃ | ||||
Generic Connector Performance:
| LC, SC, FC, ST Connector | Singlemode | Multimode | |
| UPC | APC | PC | |
| Maximum Insertion Loss | ≤ 0.3 dB | ≤ 0.3 dB | ≤ 0.3 dB |
| Typical Insertion Loss | ≤ 0.2 dB | ≤ 0.2 dB | ≤ 0.2 dB |
| Return Loss | ≧ 50 dB | ≧ 60 dB | ≧ 25 dB |
| Operating Temperature | -40℃ ~ +75℃ | ||
| Test Wavelength | 1310nm | 850nm | |
