5.5KW Grouting Mortar Cement Injection Pump 3.6m3/H
Hot Sale Mortar Cement Injection Pump Grouting Machine
Grouting Pump Features:
1. ZBS3.6/4-5.5 cement grout pump is a single cylinder double action piston pump.
2. ZBS grout pump has simple structure, light weight, small size,reliable performance, high pumping pressure.
Grouting Pump Application:
1. ZBS cement grout pump can be used to grout cement paste, mortar and other liquid (particle size ≤ 3mm).Medium temperature is between 5 to 80 ℃.The water cement ratio (weight ratio) of solid-liquid mixture should be 0.75 or higher. The maximum output pressure should be 4 MPa, and work flow 3.6 m3/h.
2. ZBS cement grout pump is widely used pressure grout in tunnels, coal mine, bridges and dams, building foundation, and other underground projects.
3. ZBS cement grout pump can work in inflammable and explosive sites,dusty and rainy environment or other bad conditions.
Technical Parameters:
|
Model
|
ZBS grouting pump
|
|
Rated output
|
3.6 m3/h
|
|
Rated pressure
|
4 Mpa
|
|
Reciprocating times
|
85/min
|
|
Motor power
|
5.5KW
|
|
Volumetric coefficient
|
≥92%
|
|
Pump efficiency
|
≥84%
|
|
Piston diameter
|
75mm
|
|
Piston stroke
|
85mm
|
|
Sipper diameter
|
20mm
|
|
Weight
|
280kg
|
|
Dimension
|
1500×500×700mm
|
