HPPV Series High Dirt Holding Capacity Polypropylene Filter Cartridge with Multi-layer Nano-fiber Material and Gradient Structure Design
Price:
To be negotiated
MOQ:
1
Delivery Time:
7 working days
Brand:
PULLNER
Product Description
HPPV Series High Dirt Holding Capacity Polypropylene Filter Cartridge
The HPPV series filter cartridge features a multi-layer Nano-fiber material with gradient structure design, delivering exceptional dirt holding capacity. Its large-to-small graded pore size enhances filtration efficiency while reducing surface clogging, significantly extending service life.
Key Features
- Multi-layer Nano-fiber construction for superior filtration
- Gradient structure design with optimized pore size distribution
- Exceptional dirt holding capacity for extended service life
- Effectively reduces surface clogging problems
- Ideal for high suspended particles, colloidal substances, and high-viscosity liquids
Applications
Perfect for industrial processes requiring filtration of challenging liquids with high particulate content or viscosity, including water treatment, chemical processing, and food/beverage applications.
Specifications
| Item | Technical Parameters |
| Filter medium | Polypropylene (PP) |
| Support/Drainage | Polypropylene (PP) |
| Core/Cage/End Cap | Polypropylene (PP) |
| Outside diameter | 2.7" (68.5mm) |
| Length | 10", 20", 30", 40" |
| Micron | 0.1um, 0.22um, 0.45um, 1um, 2um, 3um, 5um, 10um, 20um, 30um, 60um |
| Filtration area | 0.4-0.7m² |
| Max. operating differential pressure | ΔP≤0.35MPa at25℃ |
| Max. operating differential pressure (reverse direction) | ΔP≤0.28MPa at60℃ |
| Max. operating temperature | 80℃(Stainless steel support is recommended for temperature exceeds 50℃) |
| Sterilization temperature | 30 minute cycles @121℃ |
| Max. operating pressure | 4bar/21℃ |
| 2.4bar/80℃ |
Material Constructions
| Filter media | Polypropylene (PP) |
| Support/Drainage | Polypropylene (PP) |
| Cage/Core/End caps | Polypropylene (PP) |
| Seal material | Silicone, NBR, Viton, EPDM |
