PTFE Membrane Filter Cartridge with Hydrophobic and Hydrophilic PTFE Membrane for Corrosion Resistant Filtration
Price:
To be negotiated
MOQ:
1
Delivery Time:
5-7 working days
Brand:
PULLNER
Product Description
PFL/PFLH Series PTFE Membrane Filter Cartridge
The PFL series filter cartridge features a natural hydrophobic Polytetrafluoroethylene (PTFE) membrane with exceptional corrosion resistance to both organic and inorganic chemicals. This makes it ideal for sterilization filtration of highly corrosive and strongly oxidizing liquids.
The PFLH series utilizes a modified hydrophilic PTFE membrane with stable hydrophilic properties, enabling direct filtration without pre-wetting. The PTFE stretch membrane offers outstanding resistance to corrosion, oxidation, and organic solvents, along with broad chemical compatibility. It is particularly effective for particle filtration and sterilization of chemical reagents, corrosive liquids, and strongly oxidizing solutions.
Key Features
- Excellent corrosion resistance to organic/inorganic chemicals
- Superior oxidation resistance and organic solvent compatibility
- Hydrophobic (PFL) and hydrophilic (PFLH) membrane options
- Direct filtration capability with hydrophilic membrane (no pre-wetting required)
- Ideal for sterilization of corrosive and oxidizing liquids
- Wide range of chemical compatibility
Dimensions
|
Outer diameter |
2.7" (69mm) |
|
Length |
10", 20", 30", 40" |
Material of Construction
|
Filter Medium |
PTFE |
|
Support/Drainage |
PP |
|
Center core/Outer Cage/End Caps |
PP |
|
Seals Material |
NBR, Silicone, EPDM, Viton, Teflon |
Filter Performance
|
Removal rating |
For Gas: 0.04um, 0.022um |
|
For Liquid: 0.1um, 0.22um, 0.45um, 0.65um |
|
|
Max. operating temperature |
80℃ 0.17Mpa |
|
Max. tolerance temperature |
140℃ 0.27Mpa |
|
Max. operating differential pressure |
4.2 Bar @ 25℃ |
|
Max. operating differential pressure (Reverse direction) |
2.0 Bar @ 25℃ |
|
Max. temperature sterilization |
121℃, 30 minutes |
Certification
