PTFE Membrane Filter Cartridge with 0.01um Solid Particles Interception and 99.99% Efficiency for High Flow Gas Filtration
- High Efficiency: 99.99% particle retention at 0.01μm
- Versatile Performance: Maintains filtration efficiency in both dry and humid conditions due to PTFE's natural hydrophobicity
- Optimized Flow: High flow rate with minimal pressure drop
- Reliable Construction: PTFE membrane ensures consistent performance for demanding gas filtration applications
-
99.99% 10" GPF Glass Fiber Gas Filtration Membrane Filter Cartridge
DescriptionDiameter: 69mm Length: 10" Filter Medium: Glass Fiber Filtration Rating: 0.003um-0.2um MOQ: 1 Piece Delivery Time: 1 Month Sealing Material: Silicone/Viton/PEP/EPDM Max. Operating Temperature: 80℃ Max. Operating Different Pressure: 4bar/21℃ Removal Rating: 99.99% Highlight: GPF membrane filter cartridge
,69mm glass fiber filter cartridge
,GPF microfiltration cartridge
GPF High Efficient Gas Filtration Membrane Filter Cartridge
The GPF series filter cartridge is made of Polytetrafluoroethylene (PTFE) membrane, and the interception efficiency for 0.01μm solid particles is up to 99.99%, so that GPF can meet the most stringent gas filtration. PTFE membrane has natural hydrophobicity and can achieve good filtration efficiency in dry or humid conditions. High flow rate, low pressure drop.
Material Construction
Filter Media Ultrafine Glass fiber Support/Drainage Polypropylene (PP) Cage/Core/End Caps Core:SS304 or PP Seal Material EPDM, Silicone, Viton, FEP Performance
Filtration rating 0.003μm, 0.01μm, 0.1μm, 0.2μm Maximum Operating Temperature 50℃ (6 Months) Maximum Operating Differential Pressure 4bar/21℃
2.4bar/80℃
Biological Safety
Every 10 inches of dissolved matter ＜30mg Endotoxin 0.25EU/ml Ordering Information
GPF 0001 10 C1 P
Series Micron Length End Cap Type Seal Material GPF 00003 =0.003μm 05 =5" C1 =226/Spear E =EPDM 0001 =0.01μm 10 =10" C3 =222/Spear S =Silicone 0010 =0.1μm 20 =20" C5 =222/Flat V =Viton 0020 =0.2μm 30 =30" C6 =226/Flat P =FEP 40 =40" C9 =DOE ![99.99% 10" GPF Glass Fiber Gas Filtration Membrane Filter Cartridge 0]()
Tag:water filter replacement cartridges,
pleated water filter cartridges,
pleated polyester filter cartridge
![]()
FAQ
1. Q: Are you a trading company or a manufacturer?
A: We are a professional manufacturer of all kinds of filter cartridges, housings and filtration systems. We provide you the total filtration solutions with our many years experience in the industry.
2. Q: May I have samples?
A: Sure, of course. Sample cost can be refunded if you place formal orders in the future.
3. Q: Can you make customized products?
A: Yes, of course. if you can provide us detailed specifications or drawings. Our mission is make customer idea on the products and provide the customer satisfied solutions.
4. Q: Can I use our own designed package?
A: Yes, size, color, logo and packaging style all can be customized.
5. Q: What's your MOQ?
A: Normally, 100PCS/item. Any trial order which is less than MOQ is warmly welcomed. If you have a trial order, please feel free to contact us so that we can make some shipping recommendation for you to save the cost based on the quantity you need.
6. Q: I am a small business owner, Can I buy from you?
A: Yes, you are warmly welcomed. To grow with our customer is our goal. We would like to grow with you together.
7. Q: What is your general lead time?
A: Normally 5-7 working days for off-the-shelf samples and 10~15 days for bulk production.
8. Q: How should I pay you?
A: T/T, L/C, Western Union, MoneyGram, etc are acceptable.
9. Q: What certificate do you have?
A: Our factory is ISO9001/ISO14001/ISO45001 certified.
10. Q: How should I place an order?
A: Please kindly click "Sent Inquiry", Then our sales engineer will recommend you suitable products for your selection also give some valuable suggestion for your selection.
