20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction
Price:
Negotiable
MOQ:
10
Delivery Time:
7-10 work days
Brand:
Pullner
Product Description
Product Overview
Model: PPL series
Type: PP Filter
Origin: China
Technical Specifications
| Parameter | Specification |
|---|---|
| Filter Medium | Polypropylene (PP) |
| Support/Drainage | Polypropylene (PP) |
| Core/Cage/End Cap | Polypropylene (PP) |
| Outside Diameter | 2.7" (68.5mm) |
| Length | 10", 20", 30", 40" |
| Micron Rating | 0.1um, 0.22um, 0.45um, 1um, 2um, 3um, 5um, 10um, 20um, 30um, 60um |
| Filtration Area | 0.4-0.7m² |
| Max. Operating Differential Pressure | ΔP≤0.35MPa at 25℃ |
| Max. Operating Differential Pressure (Reverse) | ΔP≤0.28MPa at 60℃ |
| Sterilization Temperature | 30 minute cycles @121℃ |
| Max. Operating Pressure | 4bar/21℃, 2.4bar/80℃ |
Material Construction
Filter Media: Polypropylene (PP)
Support/Drainage: Polypropylene (PP)
Cage/Core/End Caps: Polypropylene (PP)
Seal Material: Silicone, NBR, Viton, EPDM
Applications
- Food and Beverage: Beer, wine filtration; juice and soda filtration; oral liquid filtration; additives, oil filtration
- Water Treatment: Urban water supply, industrial water filtration; power plant condensate filtration
- Metal Processing: Cutting fluid and coolant filtration; lubricating oil filtration
Packaging Details
Package Size: 62.50cm × 40.50cm × 41.00cm
Package Gross Weight: 17.000kg
Manufacturer Information
Shanghai Pullner Filtration Technology Co., LTD.
Established: 2013
Specialty: PP pleated filter cartridges, melt-blown filter cartridges, string wound filter cartridges, stainless steel filter cartridges
China Offices: Beijing, Guangzhou, Fujian, Sichuan, Guangxi, Yunnan, Xinjiang, Inner Mongolia, Shaanxi, Northeast China
Global Presence: UAE (Dubai), Malaysia (Kuala Lumpur), Russia
FAQ:
What is the brand name of this product?
The brand name is PULLNER.
What is the model number of this product?
The model number is PLZ.
Where is this product manufactured?
This product is made in China.
What is the main function of this product?
The main function of this product is to filter beverages.
What is the recommended usage time for this product?
The recommended usage time for this product is 6-12 months.
