20inch Stainless Steel Filter Cartridge with High Temperature and Pressure Resistance for Industrial Applications
PHSW series stainless steel pleated filter cartridge is made of stainless steel fiber felt by pleating wave shape, with big filtration area, high dirt holding capacity, high corrosion resistance, high pressure, high temperature. Customized on request.
| Parameter | Value |
|---|---|
| Model Number | PHSW |
| Material | Stainless Steel |
| Filter Connector | Thread |
| Filtration Grade | PRE Filter |
| HS Code | 8421999090 |
- All stainless steel construction
- Depth porous material
- Stainless steel design
- High dirt holding, long usage life
- Corrosion resistance, high pressure, high temperature
- All-welded construction, no media loss
| Component | Specification |
|---|---|
| Core/Outer Guard | SUS 304/316L Stainless steel porous plate |
| Filter Medium | Upstream Support: 30 mesh or 40 mesh stainless steel wire mesh Filter net: Required accuracy of stainless steel wire mesh Downstream Support: 30 mesh or 40 mesh stainless steel wire mesh |
| End Caps | SUS 304/316L Stainless steel |
| Max. Operating Differential Pressure | 5.0 bar |
| Max. Operating Temperature | 480℃ |
| Standard OD | Standard Length | Filter Area |
|---|---|---|
| 65mm Customized on request |
5in. (127mm) | 0.096 m² |
| 65mm Customized on request |
10in. (254mm) | 0.19 m² |
| 65mm Customized on request |
20in. (508mm) | 0.38 m² |
| 65mm Customized on request |
30in. (762mm) | 0.57 m² |
| 65mm Customized on request |
40in. (1016mm) | 0.76 m² |
Shanghai Pullner Filtration Technology Co., Ltd.
Our company has a domestic first-class physical and chemical laboratory with mass spectrometer (ICP-MS), gas chromatography (GC-MS), liquid chromatography (LC-MS), scanning electron microscope (including EDS energy spectrum), particle counter (5 sets), cartridge efficiency test bench (IFTS, France), membrane pore size distribution instrument, online particle detector, membrane test bench, permeability tester, cartridge. It can test and evaluate the performance of filter materials, cartridges and filtration equipment, and also help customers analyze the difficult problems of filtration on the production line.
