10inch 316L Stainless Steel Multilayer Sintered Wire Mesh Filter Cartridge with High Temperature and Corrosion Resistance for High Flow Applications
PHSW stainless steel multi-layer sintered mesh filter cartridge manufactured from 316L or 304 stainless steel mesh. Engineered for superior temperature, pressure and corrosion resistance with excellent backwash performance. An ideal replacement for titanium rod products, suitable for solid-liquid separation with rigid granular materials.
- Petrochemical: Various solvents, chilled water, brine filtration
- Water Treatment: Drinking water, commercial water treatment, seawater desalination RO pre-filtration
- Industrial Filtration: Energy, coatings, graphite, petrochemical, electroplating, mining, machining, industrial water treatment
- Uniform aperture distribution
- All stainless steel construction
- All-welded construction, no media loss
- High-pressure backwash capability with excellent recoil effect
- Multi-layer stainless steel sintered wire mesh
- Exceptional corrosion resistance, high pressure and high temperature tolerance
| Parameter | Specification |
|---|---|
| Filter Media | 316L/304 Stainless Steel |
| Cage/Core/End Cap | 316L/304 Stainless Steel |
| Maximum Operating Temperature | 480℃ |
| Maximum Operating Differential Pressure | 3 bar |
| OD | Standard Length | Filter Area |
|---|---|---|
| 65mm Customized on request |
5" (127mm) | 0.024 m² |
| 65mm Customized on request |
10" (254mm) | 0.048 m² |
| 65mm Customized on request |
20" (508mm) | 0.096 m² |
| 65mm Customized on request |
30" (762mm) | 0.14 m² |
| 65mm Customized on request |
40" (1016mm) | 0.19 m² |
We are a professional manufacturer of all kinds of filter cartridges, housings and filtration systems. We provide total filtration solutions with our many years of experience in the industry.
Yes, sample cost can be refunded if you place formal orders in the future.
Yes, we can manufacture customized products based on your detailed specifications or drawings. Our mission is to realize customer ideas and provide satisfactory solutions.
Yes, size, color, logo and packaging style can all be customized to your requirements.
