Stainless Steel Fiber Felt Pleated Filter Cartridge with High Dirt Holding Capacity
Price:
negotiate
MOQ:
1 pc
Delivery Time:
20-35 work days
Brand:
PULLNER
Product Description
PHSF Stainless Steel Pleated Felt Filter Cartridges are constructed with stainless steel sintered felt and shaped during the pleating process. These filters feature a large filtration area for optimal performance. The stainless steel sintered felt is manufactured from stainless steel fiber, which is sintered under high temperature to form a porous depth filtration material.
PHFS Filter Cartridges feature graded pore size distribution from coarse upstream to fine downstream, resulting in higher dirt holding capacity and extended service life.
Product Specifications
| Core/Outer Guard | SUS 304/316L Stainless steel porous plate |
|---|---|
| Filter Medium | Upstream Support: 30 mesh or 40 mesh stainless steel wire mesh Filter net: Required accuracy of stainless steel wire mesh Downstream Support: 30 mesh or 40 mesh stainless steel wire mesh |
| End caps | SUS 304/316L Stainless steel |
| Max. operating differential pressure | 5.0bar |
| Max. operating temperature | 480℃ |
Standard Dimensions & Filter Area
| Standard OD | Standard Length | Filter Area |
|---|---|---|
| 65mm Customized on request |
5in. (127mm) | 0.096m² |
| 65mm Customized on request |
10in. (254mm) | 0.19 m² |
| 65mm Customized on request |
20in. (508mm) | 0.38 m² |
| 65mm Customized on request |
30in. (762mm) | 0.57 m² |
| 65mm Customized on request |
40in. (1016mm) | 0.76 m² |
Manufacturer Profile
Shanghai Pullner Filtration Technology Co., Ltd.
Our company operates a domestic first-class physical and chemical laboratory equipped with advanced testing instrumentation including mass spectrometer (ICP-MS), gas chromatography (GC-MS), liquid chromatography (LC-MS), scanning electron microscope (including EDS energy spectrum), particle counters, cartridge efficiency test bench (IFTS, France), membrane pore size distribution instruments, online particle detectors, membrane test benches, permeability testers, and comprehensive cartridge testing equipment.
Our company operates a domestic first-class physical and chemical laboratory equipped with advanced testing instrumentation including mass spectrometer (ICP-MS), gas chromatography (GC-MS), liquid chromatography (LC-MS), scanning electron microscope (including EDS energy spectrum), particle counters, cartridge efficiency test bench (IFTS, France), membrane pore size distribution instruments, online particle detectors, membrane test benches, permeability testers, and comprehensive cartridge testing equipment.
We provide comprehensive testing and evaluation services for filter materials, cartridges, and filtration equipment performance, along with technical support to help customers analyze and resolve complex filtration challenges in production line applications.
