60Inch Length PBT Series Polyester Filter Cartridge for 120℃ High Temperature and 4bar Working Pressure
Price:
Negotiable
MOQ:
10 PCS
Delivery Time:
1 Month
Brand:
PULLNER
Product Description
60-Inch Length PBT Series All Polyester Filter Cartridge
The PBT series filter cartridge is constructed entirely from Polyester (PET) material, specifically designed for precision filtration of liquids containing aromatic hydrocarbon solvents such as benzene and toluen-e. This all-polyester construction provides excellent temperature and pressure resistance, capable of withstanding 120℃ high temperatures for extended periods and operating at 4 bar differential pressure.
Technical Specifications
| Filtration Rating | 0.2μm, 0.45μm, 1μm, 5μm, 10μm, 25μm, 50μm |
|---|---|
| Maximum Operating Temperature | 120℃ |
| Maximum Operating Differential Pressure | 4bar/21℃, 2.4bar/80℃ |
| Filter Media | Polyester (PET) |
| Support/Drainage | Polyester (PET) |
| Cage/Core/End Caps | Polyester (PET) |
| Seal Material | EPDM, Silicone, V, FEP |
Chemical Compatibility
| Chemical | Compatibility |
|---|---|
| Benzene | R (Resistant) |
| Xylene | R (Resistant) |
| Aceton-e | R (Resistant) |
| Trichloroethylene | R (Resistant) |
| CCl4 | R (Resistant) |
| Tetrahydrofuran | R (Resistant) |
| Gasoline | NR (Not Resistant) |
| Acid | NR (Not Resistant) |
Ordering Information
| Series | Micron Rating | Length | End Cap Type | Seal Material |
|---|---|---|---|---|
| PBT | 0020 = 0.2μm | 05 = 5" | C1 = 226/Spear | E = EPDM |
| 0045 = 0.45μm | 10 = 10" | C3 = 222/Spear | S = Silicone | |
| 0100 = 1.0μm | 20 = 20" | C5 = 222/Flat | V = V | |
| 0500 = 5.0μm | 30 = 30" | C6 = 226/Flat | P = FEP | |
| 1000 = 10μm | 40 = 40" | C9 = DOE | ||
| 2500 = 25μm | ||||
| 5000 = 50μm | ||||
| 4545 = 0.45+0.45μm |
Manufacturer Profile
Shanghai Pullner Filtration Technology Co., LTD.
Established: 2013
Specialty: PP pleated filter cartridges, melt-blown filter cartridges, string wound filter cartridges, stainless steel filter cartridges, and other filtration solutions.
Established: 2013
Specialty: PP pleated filter cartridges, melt-blown filter cartridges, string wound filter cartridges, stainless steel filter cartridges, and other filtration solutions.
Domestic Offices in China
Beijing, Guangzhou, Fujian, Sichuan, Guangxi, Yunnan, Xinjiang, Inner Mongolia, Shaanxi, Northeast China
Global Branches and Offices
UAE (Dubai), Malaysia (Kuala Lumpur), Russia (Moscow)
Certifications
Frequently Asked Questions
What is the brand name of this product?
The brand name is PULLNER.
What is the model number of this product?
The model number is PBT Series.
Where is this product manufactured?
This product is made in China.
