10Inch Polypropylene Pleated Filter Cartridge for High Flow Water and Beverage Filtration
High-performance PP pleated filter cartridge with 68.5mm outer diameter, designed for efficient water and fluid filtration across multiple industries.
- Food and Beverage: Beer, wine, juice, soda, oral liquid filtration; additives and oil filtration
- Water Treatment: Urban water supply, industrial water filtration; power plant condensate filtration
- Metal Processing: Cutting fluid and coolant filtration; lubricating oil filtration
- Fine Chemicals: Catalyst filtration; cosmetics raw materials and finished products filtration; chemical auxiliary filtration
- Petrochemical Industry: Aviation kerosene filtration; diesel and fuel filtration
| Item | Technical Parameters |
|---|---|
| Filter Medium | Polypropylene (PP) |
| Support/Drainage | Polypropylene (PP) |
| Core/Cage/End Cap | Polypropylene (PP) |
| Outside Diameter | 2.7" (68.5mm) |
| Length | 10", 20", 30", 40" |
| Micron Ratings | 0.1um, 0.22um, 0.45um, 1um, 2um, 3um, 5um, 10um, 20um, 30um, 60um |
| Filtration Area | 0.4-0.7m² |
| Max. Operating Differential Pressure | ΔP≤0.35MPa at 25℃ |
| Max. Operating Differential Pressure (Reverse Direction) | ΔP≤0.28MPa at 60℃ |
| Sterilization Temperature | 30 minute cycles @121℃ |
| Max. Operating Pressure | 4bar/21℃, 2.4bar/80℃ |
| Filter Media | Polypropylene (PP) |
|---|---|
| Support/Drainage | Polypropylene (PP) |
| Cage/Core/End Caps | Polypropylene (PP) |
| Seal Material | Silicone, NBR, Vit, EPDM |
Established: 2013
Specialization: PP pleated filter cartridges, melt-blown filter cartridges, string wound filter cartridges, stainless steel filter cartridges, and related filtration products
Beijing, Guangzhou, Fujian, Sichuan, Guangxi, Yunnan, Xinjiang, Inner Mongolia, Shaanxi, Northeast China
UAE (Dubai), Malaysia (Kuala Lumpur), Russia (Moscow)
The brand name is PULLNER.
The model number is PLZ.
This product is made in China.
The main function is beverage filtration and industrial fluid purification.
The recommended usage time is 6-12 months.
