10-Inch 5 Micron Melt Blown Filter Cartridge for RO Pretreatment and Water Filtration
PLM series melt-blown filter cartridges are manufactured using textile fibers (polypropylene, cotton, glass fiber) through a specialized process. These cartridges feature a porous skeleton (PP or stainless steel support) with tightly wrapped fibers that create a unique structure of loose outer layers and tight inner layers, effectively filtering suspended solids, rust, particles, and other impurities from fluids.
Product Specifications
| Outside Diameter | 60-63mm, 70mm, 115mm (Customized on request) |
| Inside Diameter | 25mm, 28mm, 30mm |
| Filter Medium | PP, Cotton, Glass Fiber |
| Length | 10", 20", 30", 40" |
| Micron Rating | 1μm, 5μm, 10μm, 20μm, 30μm, 50μm, 75μm, 100μm |
| Minimum Order Quantity | 1 Piece |
Suitable for high solid content and high viscosity material liquid solid-liquid separation
Choice of different materials configured according to process conditions to meet various liquid filtration needs
PP support offers good heat resistance, suitable for pH range 1-13
Stainless steel support provides excellent heat resistance with maximum operating temperature of 120℃
| Outside Diameter | 60-63mm, 70mm, 115mm (Customized on request) |
| Inside Diameter | 28mm, 30mm |
| Length | 5", 10", 20", 30", 40", 50" |
| Micron Rating | 1μm, 5μm, 10μm, 20μm, 30μm, 50μm, 75μm, 100μm |
| Filter Medium | Polypropylene (PP), Cotton, Glass Fiber |
| Center Core | Polypropylene (PP), Stainless Steel 304/316L |
