304/316L Stainless Steel Mesh Filter Cartridge with Multi-size Custom Micron for High Temperature Resistance
Price:
Negotiable
MOQ:
10
Delivery Time:
10-20 working days
Brand:
PULLNER
Product Description
304/316L Stainless Steel Mesh Filter Cartridge Multi-size Custom Micron
Product Overview
High-quality stainless steel mesh filter cartridges available in multiple sizes and custom micron ratings for various industrial filtration applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Filter Material | 304/316L |
| Center Rod/Enclosure/End Cap | 304/316L |
| Sealing Material | EPDM/PTFE |
| Design Pressure | 0.8 Mpa |
| Maximum Working Pressure Differential | 0.5 Mpa |
| Highest Working Temperature | 480°C |
Product Details
| Specification | Weight Range | Construction | Certification | Product Name |
|---|---|---|---|---|
| 10/20/30/40 inches 0.3um, 1um, 0.01um, 3um, Customized |
Light Weight: 0.1-2kgs, 2-20KG, 750kg, 1-100kg | SS304/SS316 | ISO9001, SGS, CE, FDA | Stainless Steel Mesh Filter Cartridges |
Applications: Air Filter, Oil Filtration, Syrup Filtration, Residential, Dust Removal, Indoor Ventilation, Viskon-Aire Spray Booth Filter, Vacuum Cleaner Parts
Company Profile
Shanghai Pullner Filtration Technology Co., Ltd.
Our company operates a domestic first-class physical and chemical laboratory equipped with advanced testing equipment including:
- Mass spectrometer (ICP-MS)
- Gas chromatography (GC-MS)
- Liquid chromatography (LC-MS)
- Scanning electron microscope (including EDS energy spectrum)
- Particle counter (5 sets)
- Cartridge efficiency test bench (IFTS, France)
- Membrane pore size distribution instrument
- Online particle detector
- Membrane test bench
- Permeability tester
We can test and evaluate the performance of filter materials, cartridges, and filtration equipment, and also help customers analyze difficult filtration problems on production lines.
Certifications
Frequently Asked Questions
What is the metal slurry filter cartridge mainly used for?
It is mainly used for the pre-filtration of new energy battery slurry, high-viscosity slurry liquids, and colloidal products. It helps remove large particles, agglomerates, and impurities before fine filtration.
What mesh sizes are available?
Common specifications include 60 mesh, 80 mesh, 100 mesh, and 120 mesh. Other mesh ratings can also be customized according to the slurry condition and filtration requirement.
What filter media can be used?
The cartridge can be made with dutch weave wire mesh, square hole mesh, or wedge wire mesh. The suitable media will depend on the slurry viscosity, particle size, flow rate, pressure, and cleaning method.
Is this cartridge suitable for final precision filtration?
It is mainly recommended for pre-filtration. For final precision filtration, it is usually used together with downstream fine filter cartridges according to the required particle control level.
How should I choose between 60 mesh, 80 mesh, 100 mesh, and 120 mesh?
A lower mesh number has a larger opening and is more suitable for coarse pre-filtration or high-viscosity slurry. A higher mesh number has a smaller opening and provides finer particle interception. The final selection should be based on slurry viscosity, particle size distribution, flow rate, pressure drop, and filtration target.
Can the size and end connection be customized?
Yes. Length, diameter, mesh rating, filter media, end cap type, sealing structure, and connection design can be customized according to the filter housing or equipment requirement.
What information is needed for quotation?
Please provide the required mesh size, cartridge dimensions, filter media type, end connection, quantity, slurry type, viscosity, flow rate, operating pressure, temperature, and whether low copper and zinc content is required. If drawings or samples are available, they will help confirm the design more accurately.
