easy operate durable roller number plate stamping machine number plate suppliers
easy operate durable roller number plate stamping machine number plate suppliers
Hot stamping technology has the following advantages over traditional mime printing processes:
· No need for mime printing and drying process, saving more intermediate costs;
·High production efficiency and the purpose of fast card issuance;
·The hot stamping process has no organic solvent discharge, and it is environmentally friendly and safe;
· Better transport safety and storage stability than ink;
· The patterned hot stamping film is anti-counterfeiting.
- l Voltage: AC220V±22V, 5a0Hz±1Hz
- l Power : single
- l Socket power: 3000W (wire is not less than 2.5 square)
- l Grounding resistance ≤ 4Ω
- l The environment is relatively closed, no obvious air flow
- l Prohibit using hot stamping equipment in ventilated place
- l The room is clean and free of debris and dust
- l No flammable or volatile flammable gas around and above the equipment;
- l It is recommended to configure one air conditioner.
- l It is recommended to configure several cameras.
- l It is recommended to configure several fire extinguishers
A machine that uses hot stamping to quickly, accurately and uniformly color embossed license plates. The machine uses fading foils of various colors to coat the embossed design.
The new technology solution implemented in this machine reduces its power consumption. Because of this, the stamping machine is an efficient machine of its kind on the market.
Parameter
| Power supply | Single phase AC220V 50Hz |
| Heating power | 2400W |
| Glue roll motor power | 90W |
| Recycling file motor power | 10W |
| Max wide | 170mm |
| Hot stamping temperature | 170℃～240℃ |
| Hot stamping gap Precision | 0.01mm |
| Conveyor belt speed | 1.8m/min |
| Preheat time | ≤40min |
| Glue roll working time | 2000h |
| NET size(L*W*H) | 870*435*525mm |
| NET weight | 160Kg |
| weight with packing | 200Kg |
| noise | ＜70DdB |
License plate hot stamping principle:
The essence of hot stamping is transfer, which is the process of transferring the ink on the hot stamping film to the license plate by the action of heat and pressure. When hot stamping, the hot melt adhesive layer of the hot stamping film is melted and adhered to the surface of the license plate, and the melt flow of the release agent layer of the hot stamping film is separated from the carrier film substrate, and the ink on the carrier film is transferred to the license plate. The reason why the transfer can be caused is that the hot melt adhesive is heated to generate a bonding force and the release agent is heated and the adhesive force is lost.
Hot stamping machine structure:
The license plate hot stamping machine is mainly composed of a film releasing device, a film collecting device, a heater, a rubber roller, a driven wheel, a brush plate, a frame, a control system and the like.
