China Workshop Motorized Platform Cart ODM Motorized Rail Cart for sale

Workshop Motorized Platform Cart ODM Motorized Rail Cart

Price Negotiable

MOQ: 1 SET

Delivery Time: 20 work days

Brand: Dowellcrane

Product Description

workshop motorized platform cart odm transfer cart

Description

workshop motorized platform cart odm transfer cart is an alternative transfer cart for rail transfer cars. It overcomes many inconvenience of rail-type electric transfer carts. The trackless electric transfer carts can finish free-turning without rail in the workshop and workshop. There is no need to lay rails, so it does not affect traffic, does not hinder production, and the flat car is more flexible, the operation is more humanized.

Features Of Transfer Cart

1. It is not restricted by the track and can travel on the ground.It can turn 360 degrees.

2. Suitable for all kinds of environments.It can be used indoors or outdoors in high temperature explosion-proof and other environments.

3. Suitable for long distance operation.

4. Customized for you.Custom table size, operating speed,load,etc.Meet your requirements.

5. Equipped with safety warning and automatic stop device.

Product Paramenters

Model		KPX-2t	KPX-20t	KPX-50t	KPX-100t	KPX-150t
Rated Load(t)		2	20	50	100	150
TableSize(mm)	Length(L)	2000	4000	5500	6500	10000
	Width(W)	1500	2000	2500	2800	3000
	Heigth(H)	150	550	650	850	1200
Wheel Base(mm)		1200	2800	4200	4900	7000
Rail Inner Gauge(mm)		1200	1435	1435	2000	2000
Wheel Diameter(mm)		270	350	500	600	600
Wheel Quantity		4	4	4	4	8
Ground Clearance(mm)		50	50	50	75	75
Running Speed(mm)		25	20	20	20	18
Motor Power(kw)		0.8	2.5	5.5	11	15
Max Wheel Load(KN)		14.4	77.7	174	343.8	265.2
Reference Weight(t)		2.3	5.5	7.6	13.9	26
Recommended Rail Model		P15	P24	P43	QU100	QU100
