Big Yellow Stone Crusher Machine For Hard Rock Basalt Crushing PE 750x1060
Big Yellow Stone Crusher Machine For Hard Rock Basalt Crushing PE 750x1060
Stone Jaw Crusher Brief Introduction:
Stone jaw crusher is widely used in mining, quarry, construction, metallurgy, highway, railway, water conservancy and chemical industries for crushing various materials with compression strength less than 350Mpa. It is preferred equipment for the complete production line as the primary crusher.
White Lai Hard Rock Stone Crusher Machine Models:
| Model | Max. Feed Size | Capacity | Power | CSS | Weight |
Dimension (L*W*H) |
| (mm) | (t/h) | (KW) | (mm) | (t) | (mm) | |
| PE-250x400 | 210 | 5-30 | 15 | 20-60 | 2.8 | 1500x1300x1300 |
| PE-400x600 | 340 | 16-85 | 30 | 40-100 | 6.5 | 1600x1700x1600 |
| PE-500x750 | 425 | 45-130 | 55 | 50-100 | 10.1 | 2000x1900x1900 |
| PE-600x900 | 500 | 50-160 | 55-75 | 65-160 | 14.13 | 2500x1900x2300 |
| PE-750x1060 | 630 | 52-180 | 110 | 80-140 | 28 | 2700x2300x2800 |
| PE-800x1060 | 650 | 85-185 | 110 | 100-200 | 30 | 2700x2300x2800 |
| PE-870x1060 | 670 | 181-210 | 110 | 200-260 | 30.5 | 2800x2300x2800 |
| PE-900x1200 | 750 | 140-280 | 110-132 | 95-165 | 50 | 3100x2800x3300 |
| PE-1000x1200 | 850 | 160-390 | 110-132 | 195-265 | 51 | 3200x2800x3300 |
| PE-1200x1500 | 1020 | 300-780 | 160 | 150-300 | 100.9 | 4900x3300x3600 |
| PEX-250x750 | 210 | 8-30 | 22 | 25-60 | 4.9 | 1500x1700x1300 |
| PEX-250x1000 | 210 | 16-68 | 30-37 | 25-60 | 6.5 | 1500x2000x1400 |
| PEX-250x1200 | 210 | 20-78 | 37 | 25-60 | 7.7 | 1500x2200x1400 |
| PEX-300x1300 | 250 | 20-118 | 55 | 20-90 | 11 | 1750x2320x1720 |
White Lai Stone Jaw Crusher Mining Equipment Features:
● High efficiency and low operation cost
● Flexible capacity
● Simple structure and easy to operate
● Over loading protection
● Easy replacement of wearing parts
● Long service life
● High reliability
● Wide ranges of choices
● Alternative ordinary and hydraulic types
White Lai Stone Jaw Crusher for Hard Rock Basalt Crushing PE-750x1060 Main Parts:
Movable Jaw Plate, Fix Jaw Plate, Toggle Plate, Mainshaft, Bearing, Pitman, etc
Big Yellow Stone Jaw Crusher for Hard Rock Basalt Crushing PE-750x1060 Pictures:
