Ceramic Lab Horizontal Bead Mill , Paint Grinder Machine Outer Material SS304

Horizontal Type Bead mill

Application

The Bead Mill is used for fine milling, dispersion, homogenisation of a suspension.

The milling/dispersion system in a Bead Mill consists of a Milling Chamber & an Agitator with Pegs and rotors .The Chamber is filled with zirconia beads & the product to be dispersed.

In the milling chamber, the grinding media is kept moving by the motor driven agitator & the product to be dispersed is pumped into the chamber through peristaltic pump.As the grinding media collides & rolls about each other, the solid particles caught between them are gradually reduced in size.

The milled product is separated from the grinding media at the outlet by a slotted screen or a gap separator, collected in a vessel & re-circulated back into the chamber via the same pump, while being continuously stirred in the same collecting vessel.

Product  Advantages

• Ultrafine grinding and dispersing technology, applicable for materials with different viscosities
• Ceramic (zirconia/ carborundum) grinding chamber to avoid pollution and improve purity of the material
• Mechanical seal with special design to facilitate stable operation
• Patented centrifugal discharge solution of Boyee which solves the blockage problem
• Better evenness for grinding with narrower peak of the distribution curve
• Independent electric box, optimized process control system and intellectual technology to help monitor the operation data
• Unique design for profile with reasonable structure and small space occupancy
• Equipment remain stale and quiet with little noise while running
• Ultrafine grinding media (as fine as 0.05mm) can be utilized without leakage or damage to the surface properties of the material

Operational safty

     For increased operationaly safety,The mechanical seal fluid is monitored continously.These data can be documented and used for predictive maintenance to ensure high availability of the machine
