Turbine Type Nano Milling Machine Ink Coating Wear Resistance Variable Frequency
Nano ceramic horizontal bead mill for ink and coating
Product Description
Application Possibilities
Turbine-type bead mill is the most efficient equipment in wet grinding machine, whose optimization design of accelerating turbine wheels provides more kinetic energy for beads in chamber. At the same time, distribution of grinding beads is more uniform ,thus distribution of fineness is much narrower .With high efficient and supper fineness performance, it is the most ideal machine for the users in packaging printing ink, color paste, car finish paint, nano materials, electronic materials, etc ...
Product Features
- Simple profile, compact conformation and easy operation
- Patented Turbine structure design and special separation and discharge system
- Double acting mechanical seal with oritented cooling loop system
- Variable frequency drive system to precisely control the grinding power
- Full-ceramic grinding part,wear-resistant and no metallic pollution
- Application of geometry to protect the grinding part of the equipment with longer lifespan
Specifications
| Grinding Chamber |
Designed Volume: 30L Effective Volume: 21L |
| Inner Chamber material:Silicon Carbide | |
| Outer Materia: SS304 | |
| Grinding Ceramic and rotor material:Zirconia | |
| Cooling Mode: Cooling water passing through grinding chamber | |
| Mechanical Sealing |
Self-developed double acting mechanical seal. Sealing Support : SS304 |
| Dispersion & Grinding structure | Ceramic turbine grinding rotors |
| Dispersing linear speed | 10-14m/sec |
| Separating mode | dynamic slotted screen separation |
| Grinding Media |
95% zirconia beads Zirconia beads spec : Dia 0.3 mm- Dia 1.0mm Filling quantity recommended:70% ᷉ 80% |
| Power | 380V/50Hz |
| Dimension | 1750(L)x 1350(W)x 1850(H)mm |
| weight |
1205Kg |
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
| Packaging | |
| Size | 1100*550*1650 |
| Weight | 80kg |
| Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
Best quality
Long-term experience, continual development work, daily contact with our customers and developments with more than 30 patents ensure the technical competence and the quality awareness of the business unit.
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for charge &you should pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
